1 Introduction Introducing your new Xerox 4112/4127 EPS Your Xerox 4112/4127 is a black and white printer. The 4112 prints at 110 pages per minute. The 4127 prints at 125 pages per minute. System components 3 1 2 5 4 No. Component Function 1 FreeFlow Print Server Provides a graphical User Interface (UI) for customizing the printer; setting up and printing jobs; managing fonts, security, accounting; and many other activities. 2 Power Switch Switches on/off the machine power.
Introduction Xerox 4112/4127 EPS For more detailed information, refer to the User Guide and Administrator Guide that were supplied with your machine.
Xerox 4112/4127 EPS Introduction No. Component Function 1 Services Press this button to access the various service screens. Services may not be available on EPS systems. 2 Control panel Select features with buttons and the keypad. 3 Touch Screen Select the available programming by touching the screen. 4 Job Status Displays the Job Status feature screens. 5 Machine Status Displays the current status of the machine on the touch screen.
Introduction Xerox 4112/4127 EPS Powering on and off Switch on the power before operating the machine. The machine warms up in approximately five minutes, after which you can make copies. Switch off the machine at the end of the day or when it is not in use for a long period of time. Power on To power on the machine: 1. Open the cover. 2. Press the power switch to the on position [|]. Note The "Please wait..." message on the UI indicates that the machine is warming up.
Using basic features 2 Exercise 1: Loading paper For this exercise, you will load 8.5 X 11 in. or A4 paper in tray 1 and load 11 X 17 in. or A3 paper in tray 3. Loading paper into Tray 1 1. Slowly pull out the tray towards you until it stops. WARNING If you pull the tray out using too much force, it can hit and injure your knees. 2. Load 8.5 x 11 in. or A4 paper and align the edge of the paper against the left edge of the tray. Note Do not load paper exceeding the maximum fill line. 3.
Using basic features Xerox 4112/4127 EPS Loading Paper into Tray 3 1. Slowly pull out the tray towards you until it stops. WARNING If you pull the tray out using too much force, it can hit and injure your knees. 2. Load 11 x 17 in. or A3 paper and align the edge of the paper against the left edge of the tray. Note Do not load paper exceeding the maximum fill line.
Xerox 4112/4127 EPS Using basic features 3. Squeeze the paper guide levers (2) and adjust the guides to match the size of your paper. 4. Push the tray in gently until it comes to a stop.
Using basic features Xerox 4112/4127 EPS Exercise 2: How to print a file from the FreeFlow Print Server The following exercise provides instructions on how to print the Quick Reference for Administrators document from your Customer Documentation CD. You should have received the CD as part of your installation package. Note After printing the document, leave it at the Xerox 4112/4127 for quick reference of System Administrator functions. 1.
Xerox 4112/4127 EPS 3. Select Browse. 4. Select the Look-In pull down menu and select CD-RW0.
Using basic features 5. Select and highlight QR_Admin.pdf from the file selection. 6. Select OK. 7. Select Print.
Xerox 4112/4127 EPS Using basic features Exercise 3: How to check the status of your job 1. Press Job Status on the User Interface. 2. Select the Active Jobs tab, which displays jobs that are printing or waiting to print. 3. Select the Completed Jobs tab, which displays all completed jobs.
Using basic features 4. Locate the print job that you completed and touch it on the touch screen to display a report. 5. Select Print This Job Report to print a hard copy. 6. Select Close.
Xerox 4112/4127 EPS Using basic features Exercise 4: How to check the machine status 1. Press the Machine Status button. 2. Read the following tab descriptions. The Machine Information tab displays the serial number, current system software version, and IP address. Buttons provide access to other information, including the Machine Configuration, Software versions, and paper tray status.
Using basic features Xerox 4112/4127 EPS The Faults tab provides access to information about faults and machine messages. • Select Current Faults and Instructions to get instructions for clearing a fault. • Select Current Messages to view actions that are needed to keep the machine operating properly. • Select Fault History to see a list of fault codes. The Supplies tab provides status information about the supplies that are used in the machine. The remaining toner is shown on a gauge.
Xerox 4112/4127 EPS Using basic features The Billing Information tab displays the serial number of the machine, the names of counters, and current counts. Select Usage Counters to view individual counters. The Tools tab provides access to setup features. Regular users have limited access to basic features. System Administrators have access to a full set of features.
Using basic features Xerox 4112/4127 EPS Exercise 5: How to call for service Refer to the User Interface when you have a problem with the machine. A status code and suggested solutions may be displayed on the screen. Follow all steps in the suggested solutions until the problem is corrected. If the problem persists, call for assistance. Before calling Xerox for assistance, gather the following information: 1. A complete description of the problem.
Computer operations 3 Note The screens shown in this section may or may not reflect your print driver screens. The screens may vary depending on your drivers configuration and marketplace. The screens shown here are a representation only. Network Printing Print procedures vary depending on the application software you are using. For more information, refer to the documentation provided with each application.
Computer operations 7. Select the appropriate Paper Tray, Paper Size, and Paper Type. 8. Select the Advanced tab and select any Advanced Features. 9. Select OK to save and close the Properties window. Xerox 4112/4127 EPS 10. Select the desired copies/quantity and OK to print the job. Note For additional information, review your print driver documentation. Printing with the PCL print drivers 1. Load the paper in the tray. See the Paper and other Media chapter in the User Guide. 2.
Xerox 4112/4127 EPS 5. Computer operations Ensure that Auto-Rotate and Center and Choose Paper Source by PDF page size are unchecked. Note These options may not be available with your version of Adobe Acrobat or Adobe Reader. 6. Select Properties and select the Paper/Output tab.
Computer operations Xerox 4112/4127 EPS 7. Click the Paper Select button. 8. If Tray 3 or Tray 4 is being used, then select Paper Settings for Auto Tray and choose the appropriate paper type. 9. Select OK twice to return to the Properties screen. 10. Select the Advanced tab and select any Advanced Features. 11. Select OK to save and close the Properties window. 12. Select the desired copies/quantity and OK to print the job. Note For additional information, review your print driver documentation.
Xerox 4112/4127 EPS Computer operations CentreWare Internet Services CentreWare Internet Services requires a TCP/IP environment, and enables you to view the status of the machine and its jobs, as well as submit jobs for printing. Print a job from CentreWare Internet Services Note Only print ready files (*.ps, *.pcl, *.jpeg, *.tiff, *.pdf, etc.) may be submitted to the device from the CentreWare Internet Services web page. 1. Start your computer and open the browser. 2.
Computer operations 3. From the CentreWare Internet Services screen, select the Print tab. Xerox 4112/4127 EPS 4. Select a file to print by clicking the Browse button and navigating to the desired file. 5. Select your desired print options. 6. Select the Submit Job button to print the job.
Quick Reference for Users 4 Getting Help For information/assistance, check the following: • User Guide for information on how to use the Xerox 4112/4127 EPS. • For online assistance go to: www.xerox.com • • Click the Support and Drivers link. • In Product Name, type 4112 or 4127 and click Search. • From the list presented, locate your model (4112 or 4127).
Quick Reference for Users Xerox 4112/4127 EPS User Interface components Component Function Control Panel Allows keypad selection of features. Touch Screen Allows selections by touching the screen. Services Component Function Press to stop the current print job or communications. Start Press the Start button to start the printing process. Does not contain features applicable to the EPS system. Numeric keypad Press these buttons to enter passwords and other numerical values.
