Document Centre Setup Guide

Page 5-18 Fax Setups
Forced 4800 (Document Centre 220/230)
Used when fax communications are susceptible to
errors.This mode is slower, but it is less susceptible to
errors.
Communication Mode (DC332/340)
This feature sets the default communication mode used for
transmission to a remote fax machine.
Super G3 automatically determines the communication mode to be
used based on the maximum capabilities of the remote fax
machine. This mode minimizes the data transmission errors
by using Error Correction Mode (ECM). Initial
communication speed is 33,600 Bits Per Second (bps).
Touch the Forced 4800
button.
Select On or Off as the
default.
Touch Save.
Touch the Communications
Mode button.
Select the default option
required - see below for a
description.
Touch Save to continue.
