Software Version 9.
Prepared by: Xerox Corporation Global Knowledge and Language Services 800 Phillips Road, Bldg. 0218-01A Webster, New York 14580-9791 USA © 1998-2008 Xerox Corporation. All rights reserved. Xerox® and the sphere of connectivity design, Xerox Nuvera®, FreeFlow®, DocuTech®, DocuSP®, DigiPath®, and CentreWare®, VIPP® (Variable-data Intelligent PostScript Printware) and "Keep the Conversation Going. Share the Knowledge." are registered trademarks of Xerox Corporation in the US and/or other countries.
Table of Contents Introduction .................................................................................................................................1 Software versions .......................................................................................................................2 New capabilities for the 9.0 software release...........................................................................3 Issues resolved in this release .........................................................
Introduction This Hints & Tips document for the Xerox® Nuvera® 100/120/144 EA Production System and the Xerox® Nuvera® 288 EA Perfecting Production System consists of the following information: • Software release deliverables and version numbers • New features in this release • Issues resolved in this release • New issues presented in this release • Known operating limitations that are to be resolved in a future release Standard system operating procedures and information can be found in the follo
Software versions This document corresponds to the following software versions: Item Version Number Free Flow Print Server 7.0 SP1 / Tigris System software RV 9.0.31.05 CP.7183.72 IPDS (must match DocuSP version) CP.7183.72 Free Flow Print Server 7.0 SP1 Remote Workflow * CP. 718372 (English) and (Multinational) CP.7182.63 Free Flow Print Server 7.0 SP1 and Variable Input version Free Flow Print Server 7.0 SP1 includes Variable Input (VI) and Variable Print Manager (VPM) version 5.0.
New capabilities for the 9.0 software release For the Xerox® Nuvera® 100/120/144 EA Production System and Xerox® Nuvera® 288 EA Perfecting Production System: • 19” monitors are standard for all configurations. • The BFM is now capable of delivering full productivity for jobs with less than 4 sheets per set provided no stapling or offsetting is required for the job. On the printer GUI select the Queue properties, then the Output tab, and set Stapling/Finishing to No Finishing and Offset to None.
For the Xerox® Nuvera® 288 EA Perfecting Production System only: • The 12.6” x 19.33” sheet feed module extends maximum paper length from 12.6 x 18.5 to 12.6 x 19.33. • Media optimization improves productivity in the following job situations: Pre-Cut tabs Small stock mixed with mostly large stock Wide Stocks measuring 9” - 9.5” process direction Optimization of job recovery for jobs containing Serialized Stocks Issues resolved in this release The following lists those Nuvera 8.
37578 The CFA cancel button is unavailable for auto MDT. 38056 In the Remote Services Transmission log, Remote Monitoring Transactions that have been initiated by Xerox are listed as being “Machine Data Transfer” operations. 40602 MFF Phase II - Hole Punch drifts during use. Every 1000 sheets it drifts 1/2 mm inboard. 40789 Print Last Sheet First option causes 1 sheet jobs to fault with a System Error message. 40905 Charge doesn't turn off when belt stops.
New issues in this release • SKEWED INSERTS WITH THE XEROX TAPE BINDER CQ#: 43471 Description: Books printed on 60gsm paper that have heavy (90gsm and higher) inserts can cause last several pages in the book to be skewed. Workaround: Recommend using inserts less than 90gsm when body is 60gsm. • ANNOTATION CQ#: 43522 Description: Do not use Annotation when feeding from the short edge feed tray and selecting the 180 rotate. The annotation will be upside-down. Workaround: None.
Release 9.0 Hints & Tips The following are the hints and tips for this release. They are intended to be resolved in the next or a future release. • PDF AND HTML FILES VIEWED FROM A CD CQ#:44223 Description: Operator needs to view PDF or HTML files on a CD. Workaround: Do one of the following: • To view PDF files, go to Launch -> Applications -> Graphics -> PDF Document Viewer and open the PDF on the CD. To view HTML files, go to System->Remote Services ->Options-> Launch Web Browser.
• UNABLE TO EJECT OR READ CD FROM GUI OR CD BUTTON CQ#:43933 Description: Operator cannot read the CD or cannot eject the CD tray from either the GUI or the CDROM button. May occur after the first successful eject. The popup menu for the CDROM is not displayed. Workaround: Take the following steps: • • Click on the “Print From File” Button and select “Browse” • Select CD in the “Look In” drop down. • Press the “Re-Display” button above the “Look In” area.
