User's Manual

X5669WUP3 User’s Manual Version 1.0

backward compatible with 802.11b

 WAN Interface

• 2-wire loop with 100 ohms line impedance in RJ-11 connector

• G.994 compliant

• G.992.1 (G.dmt) – Annex A, B, and C compliant

• G.992.2 (G.lite) – Annex A and C compliant

• ANSI T1.413 compliant

• G.992.3 (ADSL2) compliant, supporting Annex A, B, C, L and M

• G.992.5 (ADSL2+) compliant, supporting Annex A, B, C and M

• I.432 ATM physical layer compliant

 Indicators

Front panel (all LEDs in green color)

• PWR – ON when the power supply is properly connected.

• WLAN – Blinking while WLAN is transmitting data, and ON when

WLAN port is active.

• Ethernet-

• Internet-

• DSL-

Rear panel

• Each Ethernet port got speed (10/100) and activity indicators.

 OAM&P

• Through Web browser, remotely or locally

• One hidden console port (RS-232) for maintenance

 Environment

• Operation Temperature: 0°C ~ 45°C

• Operation Humidity: 5% ~ 95% (non-condensing)

• Storage Temperature: -20°C ~ +85°C

• Storage Humidity: 5% ~ 95% (non-condensing)

 Power

• AC adapter :Input 120 VAC/60Hz or 230VAC/50Hz; Output 12VDC

• Power consumption: Less than 15 watts

 Physical Dimensions

• (W × D × H) t.b.d

 Certificates

• CE, CB (TBD)
