System Status Displays
975-0210-01-01 43
System Status Messages
After installing the RC/GS and RC7, the LCD screen displays
operating system status messages which is the default screen
after exiting all other setting or meter functions. Operating
parameters include Battery State-of-charge and Set
Shorepower. The Gen Start-Stop switch is also available from
these displays.
Press the down arrow to scroll through each display. When
the last menu item is reached, the screen returns to the first
menu item.
Battery State of Charge
This meter displays a bar graph representing the estimated
state-of-charge (SOC) of the battery or battery bank. The
SOC is based on the estimated battery capacity. Since
discharging the batteries to less than one half of their amp-
hour capacity may damage the batteries, the meter estimates
the 0% SOC and protects the batteries from over discharge.
Batt State of Chg:
E !!!!!!!!! F
