Operation
42 975-0210-01-01
Inverter/Charger Current
This meter displays the actual DC current supplied to the
batteries when the RV Series Inverter/Charger is charging (+)
and current drawn from the batteries when the inverter/
charger is inverting (–).
AC Output Voltage
This meter displays the actual inverter AC output voltage
measured at the AC output. When in the charger mode (or
when the inverter is off), the meter will read “0 VAC.” When
the inverter is on, “< 40 VAC” appears if Set Idle is set to
anything other than “Defeat.”
AC Input Amps
This meter displays the actual AC current (in amps) flowing
through the inverter’s AC input hot 1 terminal when an AC
source is connected.
Inv/Chg Current:
+/- 0 Amps DC
Inverter Output:
0 VAC
AC Input:
1 Amps AC
