Operation
30 975-0210-01-01
System Status Displays
The RC/GS and RC7 remote controls display the operating
mode and system status by lighting one or more LEDs and/or
by displaying a message on the screen. The four LEDs reflect
the same information as the single tricolored LED on the RV
Series Inverter/Charger.
There are four types of system messages:
• AC source messages
• Inverter messages
• Charger messages
• Error messages.
AC Source Messages
AC source messages appear when alternating current (shore
power) is present. In addition, the AC source messages
describe the current activity, if any, of the generator (RC/GS
only).
Waiting for AC
When the inverter is off and AC is not present, the screen
displays “Waiting for AC.”
Genset Status: Pending, Cranking and Restart (RC/GS Only)
When the RC/GS is set up to start the generator for a specified
condition (battery voltage or thermostat signal) and that
condition has been met, the screen shows “Pending Genstart.”
System Status:
Waiting for AC
Genset Status:
Pending Genstart
