Indicators and Controls
975-0210-01-01 27
Inverter LED
The green Inverter LED indicates the inverter is on and ready
to provide power from the batteries. If AC power is
connected to the inverter/charger, the LED flashes. When no
AC power is connected, the inverter LED is on solid,
indicating that the inverter/charger is inverting (providing
power from the batteries). The Inverter LED also indicates
inverter status under conditions when the inverter/charger is
not inverting.
Charge LED
The yellow Charge LED indicates the current battery charge
mode.
Inverter LED Other LEDs or Devices Meaning
ON (solid) Inverter on
Flashing Yellow Charge LED
(flashing)
Inverter ready
(charging)
Slow flash Search sense mode
Flashing Error LED
ON and
buzzer sounding
Inverter error
OFF Inverter off
Charge LED Other LEDs or Devices Meaning
ON (solid) Bulk charging
Slow flash Absorption charging
Fast flash Yellow Batt. Full LED
ON Float charging
Very fast flash Equalize charging
OFF No charging
