Installing the RC/GS and RC7
The RC/GS and RC7 are designed to be flush mounted
through an opening in a wall and secured with four screws.
The RC/GS and RC7 require no connections other than one
cable that plugs into the back of the unit. Because you cannot
access the cable jack once the unit is mounted, the cable
needs to be routed through the wall before securing the
remote.
All operating power for the RC/GS and RC7 is provided by
the RV Series Inverter/Charger through the cable.
Materials and tools required
You will need these materials and tools to complete the
installation:
❐ level, measuring tape, and pencil
❐ four #6 screws and appropriate screwdriver
❐ jigsaw or small keyhole saw
❐ power drill with 1/16" bit (optional)
❐ RC/GS and RC7 remote cable (telephone-style cable if
connecting to a GS-series inverter/charger, data-standard
cable if connecting to a non-GS series inverter/charger).
CAUTION
Allow at least 2 ¼ inches (57 mm) of space behind the wall to
accommodate the depth of the unit and allow room for the cable to
bend.
