Introduction
4 975-0210-01-01
Indicators and Controls
All operating controls and indicators are located on the front
panel of the remote control.
O
N/OFF Control The inverter portion of the inverter/
charger can be switched
OFF or ON using the remote control.
The standby charger in the inverter is automatic and always
ready and available for charging whenever AC power is
applied.
Meters The RC/GS and RC7 feature several meters that
monitor the operating conditions of the power center. These
meters include: Average Shunt Amps, Battery Voltage,
Inverter/Charger Current, AC Output Voltage, AC Input
Amps, and Estimated Battery Capacity.
Controls The RC/GS and RC7 allow the inverter to be
switched
ON or OFF with the press of a button on the remote.
The RC/GS and RC7 can be used to configure the inverter/
charger to the specific system and preferences including
Battery Capacity, Battery Type, Charger Rate, Shorepower
Amps, and LCD screen Contrast. In addition, the RC/GS
starts and stops the generator automatically or manually,
allows the setting of generator make and model, sets a “quiet
time” during which the generator will not start automatically,
and has manual overrides for auto gen start.
Status Monitoring The RC/GS and RC7 monitor operating
conditions, including the AC supply, inverter operation,
charger operation, battery condition, and (on the RC/GS
only) generator condition.
