4 Appendix
4.1 Technical data
iCPlate2 X iCPlate2 XT
Functions Dot area % X X
Screen ruling in lines/cm or lines/inch X
Dot diameter X
Screen angle X
Visual coverage X
Binary image display 6,350 ppi 6,350 ppi and 12,700 ppi
Plate characteristic curve 100 measurements
References 100 references
Test measurements Standard plates X X
Polyester plates X X
Film X
Paper X
Positive and negative samples X X
Regular screen (AM) X X
Stochastic screen (FM) 1st and 2nd order X X
Measurement technique Sensor CMOS 648 x 488
Sensor resolution 12,700 ppi
Viewing area per pixel 2
µm x 2µm
Viewing area ca. 1.3mm x 1mm
Analysis Image analysis algorithms
Illumination RGB LED ring optics
Repeatability ± 0.5%
Measurement time 3.4 sec (typ.)
Screen ruling range (AM) 26 l/cm – 147 l/cm
