Example: Measuring a plate characteristic curve with the sample

points 5, 10, 30, 60 and 90 (45° reference curve):

• Select the function with the <UP> or <DOWN> button and

execute this using the <ENTER> button. All reference values are

reset. The nominal value 5% and the reference value 5% are shown.

• Measure the 5% patch. The measured value is shown at the top

edge of the Y axis and the 5% reference value is shown below it.

The nominal value of 10% and the reference value of 10% are

shown for the next patch.

• Measure the 10% patch. The measured value is shown at the top

edge of the Y axis and the 10% reference value is shown below it.

The nominal value of 30% and the reference value of 30% are

shown for the next patch.

• Should you have measured the 20% patch instead of the 10%

patch, put the measurement cursor back by one patch by selecting

the function with the <UP> or <DOWN> button and then

pressing the <ENTER> button. The nominal value, reference value

and current measurement value will be put back accordingly.

•

Measure the 30%, 60% and 90% patch in the same way. No

new nominal value will be shown now. The curve can then be

transferred to the host PC by selecting the icon and pressing

the <ENTER> button.
