3.4 FOGRA Measuring Bar FMB setting
Select the measurement mode in the device setting
(chapter 3.2.3.3):
iCPlate2 measurement mode
The iCPlate2 measures according to the X-Rite iCPlate2 (or iCPlate II)
standard. The iCPlate2 measures compatible to all other iCPlate2 (or
iCPlate II) devices. In this mode the iCPlate2 uses the specially
developed plate measurement algorithm, where the dots can be
accurately detected.
FOGRA Measuring Bar FMB measurement mode
The iCPlate2 measures according to the FOGRA Measuring Bar
FMB standard. This reference for check-up measurements is the
offset sample plate
Fogra Measuring Bar FMB from the German
research institute Forschungsgesellschaft Druck, fogra e.V., München.
Fogra Measuring Bar FMB can be ordered over the internet at
www.fogra.org.
fogra Forschungsgesellschaft Druck e.V.
Streitfeldstr. 19 • D-81673 München/Germany
Phone: [phone] • Telefax: [phone]
