User guide

3.2 First steps for use

Release the measuring head by sliding the locking device on the left

side forward. After opening initially or after pressing the <RESET>

button (red button on the bottom side of the measuring head, the start-

up screen appears on the display.

The version number of the firmware and the device serial number are

shown on the bottom left of the screen. If you have technical queries,

please communicate this information to the manufacturer.

The device’s factory settings have been selected to enable you to begin

measuring plates immediately. The iCPlate2 is configured as follows:

•

Standard plate

•

Lines/cm

•

Regular screen (AM)

•

Red LED (a standard plate is typically measured with the red LED)

3.2.1 Power-saving mode

The iCPlate2 changes over automatically to power-saving mode after

approximately 20 seconds. This is announced by displaying the

‘Sleep’ symbol. The display will then fade out. Tapping any

button on the device will reproduce the last display.

iCPlate2

3•Operation
