Extension Cords
When selecting an extension cord for use with Wyco electric motor cord sets using a three-prong polarized plug, an
equivalent plug set must be used for the grounded or earthed version.
MPORTANTI
A grounded or earthed motor requires a grounded or earthed extension cord.
A two-prong extension cord may be used for the double insulated motor. Extension cords must be approved for outdoor use
and the wire gauge of the cord must be appropriate for the expected load. See Table 5.
Motor Type Voltage Rated Amps Minimum Wire Size Maximum Cord Length
WSD1
115 V AC(±15V AC) 15
14 AWG 100 ft (30.48 m)
WSD1T
WSG1
WSG1T
W994D1
W994D1T
W994G1
W994G1T
12 AWG 150 ft (45.72 m)
WVD1
WVD1T
WVG1
WVG1T
WSG2
230 V AC (±30V AC) 7.5
16 AWG 100 ft (30.48 m)
WSG2T
WVG2
14 AWG 150 ft (45.72 m)
WVG2T
W994G2
16 AWG 100 ft (30.48 m)
W994G2T
Table 5: Extension cord wire minimum size requirements
ELECTRIC VIBRATOR HEAD ASSEMBLY DRAWINGS & PARTS LISTS
Vibrator
Head Model
Marking on
End Cap
Square
Size in. (mm)
Assembly
Part No
Vibrator
Head Model
Marking on
End Cap
Square
Size in. (mm)
Assembly
Part No
750-D D 3/16 (4.76) W877-520 750-GI 1.75B 1-3/4 (44.45) W878-540
750-EH EH 1 (25.4) W877-526 750-LI 2.00B 2 (50.8) W878-563
750-FI 1.38B 1-3/8 (34.92) W878-533 750-MI 2.25B 2-1/4 (57.15) W878-568
Table 6: Electric vibrator head models
OTE:N Vibrator head model 750-SBI is a 2-1/2 in (63.5 mm) round head with no end cap marking.
Assembly PN is # W877-512.
