(2) RT-5000 Transceiver (P/N’s 400-015525-0101 to 0501)
Connector J101 Pin Names.
PIN SIGNAL NAME PIN SIGNAL NAME
A AUX AUDIO IN i GUARD AUDIO INHIBIT
B AUX SIDETONE j AUDIO HI OUT
C RES SPARE A k AUDIO LO OUT
D CONTROL GND m AUDIO GND
E RS-422 ANT TX H n EXTRA WB MAIN RX AUDIO
F RS-422 ANT TX L p MAIN SQUELCH DISABLE
G RS-422 ANT RX L q WIDE BAND MN RX AUDIO OUT
H RS-422 ANT RX H r DF ENABLE
J RS-422 CTRL TX HI s DF AUDIO
K RS-422 CTRL TX LO t RES SPARE B
L RS-422 CTRL RX LO u HOMING SIGNAL STRENGTH
M RS-422 CTRL RX HI v MN RX 180 ENABLE
N DATA SHIELD GND w WIDE BAND GD RX AUDIO OUT
P MAIN SQUELCH ANNUN x GD RX 180 ENABLE
R GUARD SQUELCH ANNUN y GUARD RX AUDIO
S AM/FM MODE INDICATOR z TX 180 ENABLE
T VHF/UHF MODE INDICATOR AA 28 VDC PWR
U VHF_LO MODE INDICATOR BB 28 VDC PWR
V ATTENUATOR CONTROL CC 28 VDC PWR
W ON/OFF DD 28 VDC PWR
X GUARD SQUELCH DISABLE EE PWR GND
Y MIC HI IN FF PWR GND
Z MIC LO/PTT IN GG PWR GND
a EXTERNAL PTT HH PWR GND
b PTT OUTPUT
c SWITCHED +15V
d TX SWITCHED +15V
e SWITCHED +27.5V
f MAIN AUDIO INHIBIT
g EXTRA WIDE BAND AUDIO IN
h WIDE BAND AUDIO IN
Table 4-5. RT-5000 Transceiver (P/N’s 400-015525-0101 to 0501)
Connector J101 Pin Names
