Installation Guide

3of3
STEP 7 Install Ceiling Canopy-
A. Carefully tuck all wires into the outlet box and position the Ceiling
Canopy (B) over the outlet box. Attach the Ceiling Canopy (B) over
the mounting screws and secure with previously removed mounting
balls. Hand tighten until snug.
Figure 7
Figure 8
STEP 8 - Install Glass Shades and Bulbs
A. Remove socket collar and steel collar from the fixture body.
B. Place the Glass Shade (G) and the steel collar over the socket and
secure with socket collar. Hand tighten until snug.
C. Insert bulbs onto sockets and screw snugly into place.
Your fixture is now assembled and ready to use. Enjoy!
Mounting Screw
Mounting Ball
B
A
FINISH: POLISHED CHROME
GN
D
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/4"
Socket
Steel Collar
Socket Collar
Bulb (not included)
G
4.5”
1”
42”
43.75”
9”
7.25” Dia.
8.25”
98”
