Operation Manual

10
Lithium-ion Brushless Impact Driver EN
WARNING–To reduce the risk of
injury, user must read instruction
manual
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Do not expose to rain or water.
Do not burn
Li-I on
Li-Ion
Do not dispose of batteries,
Return exhausted batteries to your
local collection or recycling point.
High speed
Low speed
SYMBOLS OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE
The power tool is intended for driving in and
loosening screws.
ASSEMBLY AND
OPERATION
ACTION FIGURE
BEFORE OPERATION
Checking the battery pack
condition
See Fig A1
Removing the battery pack See Fig.A2
Charging the battery Pack See Fig.A3
Installing the battery pack See Fig.A4
ASSEMBLY AND ADJUSTMENT
Assembling the Hook and Bit
Holder
Warning: To reduce the
risk of serious personal
injury, do not suspend the
tool overhead or suspend
objects from the belt hook.
Only hang tool’s belt hook
from a work belt.
See Fig. B1,
B2,B3,B4
Inserting and Removing Bits and
Socket
See Fig.
C1, C2
Forward/Reverse/Lock
Warning: Never change the
direction of rotation when
the chuck is rotating, wait until it
is stopped!
See Fig.
D1,D2,D3
OPERATION
Operating the On/Off Switch
Warning: Do not operate
for long periods at low
speed because excess heat
will be produced internally.
See Fig. E
