Lithium-ion Brushless Impact Driver EN
TECHNICAL DATA
Type WX292 WX292.1 WX292.9 (2- designation of machinery, representative of Cordless
Impact Driver)
WX292 WX292.1 WX292.9
Charger voltage 100-240V ~50/60Hz
Rated voltage 20V Max**
No load speed 0-2900/min
Impact rate 0-3200Ipm
Max torque 175N.m
Chuck capacity 1/4”
Machine weight 1.44kg 1.7kg 0.84kg
** Voltage measured without workload. Initial battery voltage reaches maximum of
20 volts. Nominal voltage is 18 volts.
NOISE INFORMATION
A weighted sound pressure L
pA
: 76dB(A)
A weighted sound power L
wA
: 87dB(A)
K
PA
& K
WA
3.0dB(A)
Wear ear protection when sound pressure is over
80dB(A)
1. FORWARD/ REVERSE ROTATION CONTROL
2. SOFT GRIP HANDLE
3. BELT HOOK
4. BATTERY PACK RELEASE BUTTON
5. BATTERY PACK
6. ON/OFF SWITCH WITH VARIABLE SPEED CONTROL
7. SIGHT LIGHT
8. COLLET LOCKING SLEEVE
9. BIT CLIP
10. BATTERY CAPACITY INDICATOR
