SAFETY INSTRUCTIONS Read all of these instructions before operating and save instructions for later use. 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. Read Instructions – All the safety and operating instructions should be read before the appliance is operated. Retain Instructions – The safety and operating instructions should be retained for future reference. Heed Warnings – All warnings on the appliance and in the instructions should be adhered to.
INTRODUCTION Thank you for purchasing the Audioaccess W.H.E.N. Whole House Entertainment Network. This system utilizes the vast technological resources of the Harman International Companies to create a whole new approach to multi-room audio/video entertainment. With most whole house systems, Home Theater is a secondary aspect of system design and application.
KEY FEATURES Main Room • 70 Watts x 7 channel surround mode • Dual AM/FM Tuners. • 3 dedicated RS232 Sony ES DVD Changer Interface Ports. • DCDi™ by Faroudja® video up-converter scales all inputs to 1080i via an HDMI and component video outputs. • Video parameters are adjustable separately for each video input. • Surround modes include: Dolby Digital EX, Dolby Pro logic 2, Dolby Pro Logic IIx, Dolby Headphone, DTS, DTS Neo 6, Logic 7.
TYPOGRAPHICAL CONVENTIONS In order to help you use this manual with the remote control, front-panel controls and rear-panel connections, certain conventions have been used. EXAMPLE – (bold type) indicates a specific remote control or front-panel button, or rear-panel connection jack. EXAMPLE – (OCR type) indicates a message that is visible in the on-screen display (OSD). EXAMPLE – (OCR Italic type) indicates a message that is visible on the AVR front-panel information display.
IMPORTANT SAFETY INFORMATION Verify Line Voltage Before Use Your AVR21EN has been designed for use with 120-volt AC current. Connection to a line voltage other than that for which it is intended can create a safety and fire hazard and may damage the unit. If you have any questions about the voltage requirements for your specific model, or about the line voltage in your area, contact your selling dealer before plugging the unit into a wall outlet.
Cleaning When the unit gets dirty, wipe it with a clean, soft, dry cloth. NEVER use benzene, aerosol cleaners, thinner, alcohol or any other volatile cleaning agent. Do not use abrasive cleaners, as they may damage the finish of metal parts. Avoid spraying insecticide near the unit. Moving the Unit Before moving the unit, be certain to disconnect any interconnection cords with other components, and make certain that you disconnect the unit from the AC outlet.
WHAT’S INCLUDED AVR21EN Carton Contents: 1 - AVR21EN Processor/Controller 1 - AVR21ENR1 Remote Control 1 - Calibration Microphone 4 - AAA Batteries 2 - AM Loop Antennas 2 - FM Antennas 1 - IEC Standard two prong power cord 1 - W.H.E.N. Installation Instructions 1 - Warranty Card AVH21 Carton Contents: 1 - AVH21 W.H.E.N.
SYSTEM PLANNING The Audioaccess W.H.E.N. System is made up of three main system components, (AVR21EN Processor/Controller, AVH21 A/V Hub, WPS21 Power Hub) and three user interfaces (AVR21ENR1 Main Room Remote, KP21 Keypad, KP21R Remote Room Remote). When designing a whole house system, careful planning must be made to be sure the system has been designed properly, gets installed and configured properly and most important, works the way the homeowner wants the system to work.
SYSTEM PLANNING Remote Rooms The AVR21EN has a special Multiroom Link that provides a network connection to the AVH21 Audio/Video Hubs via CAT5e cable. The Multiroom Link feeds digital audio to the AVH21s for distribution to the KP21 Keypads and receives control signals from the remote rooms for zone, source and system control. Each AVH21 requires a WPS21 Power Hub. The WPS21 provides individual power terminals to provide power to the AVH21 A/V Hub and each of the keypads connected to that AVH21.
PRE-WIRE As part of System Planning, full consideration should be given to the wiring infrastructure that will be required to utilize the maximum capabilities of the Audioaccess W.H.E.N. Main Room This section is an overview of the pre-wiring that that should be done during construction and prior to installation for the Main Room section of the system. Speakers (Front, Side, Rear) Pull quality, 16AWG, 2-conductor stranded speaker wire from each speaker location to the AVR21EN.
PRE-WIRE Remote Rooms This section is an overview of the pre-wiring that that should be done during construction and prior to installation for the Remote Room sections of the system. NOTE: This section assumes that the AVR21EN, AVH21(s) and WPS21(s) are all in the same location.
AVR21EN FRONT PANEL FEATURES 1. 2. 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17.
AVR21EN FRONT PANEL FEATURE DESCRIPTIONS 1. Main Power Switch: Press this switch to apply power to the AVR21EN. When the switch is pressed in, the unit is placed in a Standby mode, as indicated by the light in the Standby/On Button [square 2] turning red. The switch MUST be pressed in to operate the unit. To turn the unit off and prevent the use of the remote control, this switch should be pressed until it pops out from the front panel. NOTE: This switch is normally left in the “ON” position. 2.
Speaker, Channel, Digital Sel and Delay Mode parameters. For example, press Tone Mode. TONE IN/OUT will appear on the lower display line [square 34]. Press one of the Mode Adjust Buttons [squares 7, 9] to select TONE IN. Press Tone Mode [square 30] again. TREBLE MODE will appear in the lower display line. Press the Set Button [square 8]. The numeric value for the treble adjustment will appear in the Lower Display Line [square 34].
MANUAL/MONO tuning mode. Press again to switch back to AUTO/STEREO mode. (See section: Main Room Operation/Tuner Operation for more information on using the tuner.) 19. Game/Cam Component Video Input: These component video jacks may be used as either inputs or outputs for temporary connection to video games or portable audio/video products such as a camcorder. (See section: Main Room Operation/Front Panel Connections for more information on switching these jacks between an input and output.) 20.
29. Speaker Selector: Press this button to begin the process of configuring the AVR21EN for the type of speakers it is being used with. For complete information on configuring the speaker settings, see section: AVR21EN Configuration/Speaker Setup. 30. Tone Mode Selector: This button controls the tone mode settings, enabling adjustment of the bass and treble boost/cut. You may also use it to take the tone controls out of the signal path completely for “flat” response.
34. Lower Display Line: Depending on the unit’s status, a variety of messages will appear here. In normal operation, the current surround mode will appear on this line. 35. Speaker/Channel Input Indicators: These indicators are multipurpose, indicating both the speaker type selected for each channel and the number of audio channels available.
AVR21EN REAR PANEL FEATURES Figure 3 AVR21EN Rear Panel 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. 26. 27.
28. 29. 30. 31. 32. 33. 34. 35. 36. 37. 38. 39. 40 41. 42. 43. 44. 45. 46.
AVR21EN REAR PANEL FEATURE DESCRIPTIONS 1. Disc 1 Analog Audio/Video Inputs: Connect the left/right analog audio and composite or SVideo jacks of a DVD/CD player or other video source to these jacks. When digital audio and/or component video outputs are used with a DVD/CD player and the AVR21EN, the default connection points are the Coaxial 1 Digital Audio Input [circle 19] and the Disc 1 Component Video Inputs [circle 9].
9. Disc 1 Component Video Inputs: Connect the component video outputs of a DVD player or any other video source equipped with Y/Pr/Pb or RGB component video outputs to these jacks. The factory default is for these jacks to be linked to the Disc 1 Analog Audio Inputs [circle 1] and the Coaxial 1 Digital Audio Input [circle 19], but you may change the digital audio input setting at any time through the MAIN ROOM/SOURCES menu as described in Main Room Setup/Source Audio Input.
[circle 19] is assigned as the default to Disc 2, but both can be reconfigured as optional inputs to other sources. 20. Center Speaker Output: Connect these outputs to the matching + and – terminals on your center channel speaker. In conformance with the CEA color-code specification, the green terminal is the positive (+) terminal that should be connected to the red (+) terminal on speakers with the older color-coding.
30: Multiroom Link: These two RJ45 jacks may be used to add up to 20 additional rooms of audio/video signal distribution and system control when connected to Audioaccess W.H.E.N. AVH21 Audio/Video Hubs. They may also be used to add two additional rooms of audio distribution when each is connected directly to an Audioaccess W.H.E.N. KP21 Keypad. (See sections: Main Room Installation & Setup/Multiroom Link and AVH21Connections/Uplink/Multiroom Link for additional information.) 31.
1080i and sent through the Component Video Monitor [circle 15] or HDMI Jacks [circle 18] with the OSD messages. 41. Door A/V Audio Input: Connect this jack to the line level audio output of a door monitoring or paging device. 42. Door A/V Composite Video Input: Connect this jack to the composite video output of a door monitoring device or security camera. 43. Tuner 1 FM Antenna Jack: Connect the supplied indoor or an optional external FM antenna to this terminal. 44.
NOTE 2: If a source has somehow turned OFF, and is being sensed via SPF, if a source function command is sent from a keypad or remote, (DVD play, etc) the AVR and SPF will ‘see’ the function command, know the source is off and turn the source on automatically. Figure 4 SPF Source Power Flag - Top View 1. 2. 3. 4. 5. 6. Signal Input Signal Output Mini Plug Pigtail Red Power LED (side) Power Input Power Pass-Through Figure 5 SPF Source Power Flag - Side Views SPF FEATURE DESCRIPTIONS 1.
Through connects to the Power Input jack on next SPF using the included 2.1mm to 2.1mm coaxial plug jumper wire. Up to six SPF’s can be powered from one SPF/PS.
AVR21ENR1 REMOTE FEATURES 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. 26. 27. 28. 29. 30. 31. 32. 33. 34. 35. 36. 37. 38. 39. 40. 41. 42. 43. 44. 45. 46. 47. 48. 49. 50. 51. 52. 53.
AVR21ENR1 FEATURE DESCRIPTIONS NOTES: • The function names shown here are each button’s function when used with the AVR21EN. Most buttons have additional functions when used with other devices, and some of these functions may be assigned to different buttons, depending on which device was selected. The device name will appear in the upper line of the LCD Information Display [oval 3] and the function assigned to that device will appear in the lower line when the button is pressed.
6. TV Mode Select: Press this button to switch the remote keys to directly control the local TV or video display. 7. 6CH/8CH Input Select: Press this button to select the device connected to the 8-Channel Direct Inputs [oval 7]. (See section: Main Room Installation & Setup/8 Channel DVD Audio for more information.) 8. Faroudja Processor On/Off: Press this button to activate the Faroudja DCDi Processor. Press again to de-activate the processor.
by changing to monaural reception. See section: Main Room Operation/Tuner Operation for more information on tuner operation. 15. Guide/Level Button: This button is used to start the process of manually setting the AVR21EN’s speaker output levels. While a reference source is playing, press this button, and then press the ▼/▲Navigation Button [oval 16] until the channel to adjust appears.
22. Record/Stop/Pause Transport Controls: These buttons have no direct function on the AVR21EN, but are used when the remote is programmed for a compatible DVD, CD or tape player. Pressing these buttons will transmit a stop, record, or pause command, according to the capabilities of the player being controlled. 23. Status/Setting Buttons: This button has different functions, depending on which device is in use. Press it to display an external DVD recorder’s status.
back to 90 minutes, and so forth. When the Sleep timer is in use, the front-panel displays will dim to half brightness. 34. Night Mode/PIP Channel Down Button: After pressing the AVR Button, this button activates the Night mode, preserving dialogue (center-channel) intelligibility at low volume levels when available in specially encoded Dolby Digital sources. 35. PVR Live Button: When a PVR is in use, this button switches to play of the signal currently being received by the PVR.
button will cycle through the available slow-play speeds of 1/2x, 1/4x and 1/8x. Pressing the left side of the button switches to the DVD slow reverse play mode. Additional presses of the left side of the button cycles through the available slow-play speeds of 1/2x, 1/4x and 1/8x. No slow-play speeds are available for CDs or other disc types. 42. Preset/Page Up/Forward Skip Button: This multipurpose button has a different function depending on the source in use.
50. 12V Trigger Button: Press this button to toggle the 12V Trigger Out Jack [circle 38] on the AVR21EN rear panel to activate a voltage controlled device such as a screen, lift, lights, drapes or A/V components. This jack turns on and off with AVR power status. The Trigger button turns the control voltage from this jack ON/OFF while the AVR is ON. 51. Mute Button: Press this button to momentarily silence the AVR21EN. Press it again, or use the Volume Up/Down Control [oval 20] to restore audio. 52.
AVR21ENR1 FUNCTION LIST Figure 8 AVR21ENR1 Button Locations 41
No.
MAIN ROOM INSTALLATION & SETUP Figure 10 Typical Main Room Connections Installing AVR21EN and Source Components After unpacking the unit, locating it in a place with adequate ventilation and placing it on a solid surface capable of supporting its weight, you will need to make the connections to your audio and video equipment.
AVR21EN CONNECTIONS Source Connections We recommend that you use high-quality interconnect cables when making connections to source equipment and recorders to preserve the integrity of the audio/video signals. NOTE 1: The analog audio video connections provided are system defaults for source audio video signal inputs when a source is selected. NOTE 2: The digital audio connections provided are system defaults for source digital audio inputs.
Coaxial Digital Audio 1. Connect the Coaxial Digital Output of a DVD/CD player to the Signal Input Jack [star 1] on a SPF. 2. Connect the Signal Output Jack [star 2] on the SPF to the Coaxial 1 [circle 19] jack on the AVR rear panel. 3. Connect the 3.5mm mini-plug pig-tail [star 3] to the Disc 1 SPF IN [circle 39] on the AVR rear panel. 4. If using one SPF, connect the Power Input to an Audioacess SPF/PS Power Supply.
aDock and aDock A/V Adaptor Connections 1. Connect the DB15 cable that is attached to the aDock to the aDock A/V Adaptor as shown in Figure 11. This will provide power and control to the iPod and send A/V signals and metadata to the AVR21EN. 2. Connect a DB9 cable from the aDock A/V Adaptor to the Disc 3 DVD Changer Interface Terminal [circle 34] on the AVR21EN Rear Panel as shown in Figure 11. This will provide control to the iPod and send A/V signals and metadata to the AVR21EN.
1. Connect the composite video output of a Video Recorder to the Signal Input Jack [star 1] on a SPF. 2. Connect the Signal Output Jack [star 2] on the SPF to the VR C-VID IN [circle 4] jack on the AVR rear panel. 3. Connect the 3.5mm mini-plug pig-tail [star 3] to the VR SPF IN [circle 39] on the AVR rear panel. 4. If using one SPF, connect the Power Input [star 5] to an Audioaccess SPF/PS Power Supply.
3. Connect the 3.5mm mini-plug pig-tail [star 3] to the CABLE/SAT SPF IN [circle 39] on the AVR rear panel. 4. If using one SPF, connect the Power Input [star 5] to an Audioaccess SPF/PS Power Supply. If using multiple SPFs, connect the Power Input [star 5] to the Power PassThrough [star 6] on the previous SPF using the included 2.1mm jumper wire. Coaxial Digital Audio 1. Connect the Coaxial Digital Output of a Cable Box/Satellite Receiver to one of the Signal Sense IN/OUT Jacks [star 1] on a SPF. 2.
SPF (Power Management – Optional) - AUX NOTE: An SPF (Source Power Flag) should be used on any device that does not have discreet IR ON/OFF codes. Either composite video or Coaxial Digital Audio can be sensed. All SPF modules can be daisy-chained together for power from a single SPF/PS power supply and must be powered to work. (See section: SPF Features) Composite Video 1. Connect the composite video output of an A/V device to one of the Signal Input Jack [star 1] on a SPF. 2.
MONITOR OUTPUTS (MAIN ROOM VIDEO DISPLAY) Composite/S-Video When connecting the AVR21EN to a standard, analog video display that only has standard composite and S-Video inputs, the component video inputs on the AVR21EN may not be used. 1. Connect the Composite and/or S-Video Monitor Outputs [circle 40] to the matching composite and S-Video inputs on your video display, depending on which types of video are output by your source devices. Component Video 1.
SPEAKER CONNECTIONS Figure 12 Speaker Connections 1. Connect the front, center, surround and surround back speaker outputs [circles 20, 21, 22, 23] to their respective speakers, using quality 14AWG two-conductor stranded speaker wire. NOTE 1: 16AWG wire may be used for short runs of less than 10 feet. We do not recommend that you use cables with an AWG equivalent of 18 or higher (smaller gauge), due to the power loss and degradation in performance that will occur.
NOTE 3: While most speaker manufacturers adhere to an industry convention of using black terminals for negative and red ones for positive, some may vary from this configuration. To ensure proper phase and optimal performance, consult the identification plate on your speaker or the speaker’s manual to verify polarity. If you do not know the polarity of your speaker, consult the speaker’s manufacturer.
components will also be controlled with the IR commands from the remote sensor or repeater system. RS-232 The RS232 Port is currently used for factory testing and software updates. No connection is required. Multiroom Link The Multiroom Link connects the AVR21EN to the AVH21 A/V Hubs in multiroom applications. Connect a CAT5e cable terminated with RJ45 connectors from the Uplink Terminal [pentagon 16] on an AVH21 to the Multiroom Link Terminal [circle 30] on the AVR.
Figure 13 Front-channel Speaker Positioning Figure 14 Surround & Rear Speaker Positioning When the AVR21EN is used in 5.1-channel operation, the preferred location for surround speakers is on the side walls of the room, no more than 10 degrees off axis from the listening position. In a 7.1-channel system, both side surround and back surround speakers are required. The center of the speaker should face into the room. Rear surround speakers are required when a full 7.
wall, behind the listening position. When placing surround speakers, it is recommended that they be located so that none of the speakers is more than two feet higher than the other. If dipole-type speakers are used on either the side or rear walls of the room, please note that if there are arrows on the speakers they should face the front of the room for the side speakers, or toward the center of the wall for the rear speakers.
5] or any of the Input Selectors [oval 4] on the remote. The LED in the Standby/On Button [square 2] will turn green to confirm that the unit is on. Using the On-Screen Display When making the following adjustments, you may find it easier to use the AVR21EN’s on-screen display system. These easy-to-read displays give you a clear picture of the current status of the unit and make it easy to see which speaker, delay, input or digital selection you are making.
To use the full-OSD menu system, press the AVR Button [oval 5] followed by the MENU Button [oval 44]. When the menu is on the screen, press the ▼/▲ Navigation Button [oval 16] until the on-screen cursor is next to the item you wish to adjust, and then press the Set Button [oval 18] to adjust that item. The menus will remain on the screen for 20 seconds, and then they will “time-out” and disappear from the screen.
Input Setup The first step is to configure each input. Once an input is configured, the selection of an input will automatically recall those settings from a nonvolatile memory. For that reason, the procedures described below must be repeated for each input source so that you have the opportunity to customize each source to your specific listening and viewing requirements. However, once made they need not be changed again unless you need to alter a setting.
cursor to 5.1 CHANNEL if using a Front/Rear/Sub speaker configuration or 7.1 CHANNEL if using a Front/Side/Rear/Sub speaker configuration and press the Set Button [oval 18]. Select YES in the ARE YOU SURE YOU WANT TO CHANGE…? window. The System Configuration Menu will appear. Using the ▼/▲ Navigation Button [oval 16], align the cursor with BACK TO MAIN ROOM. Press the Set Button [oval 18]. The MAIN ROOM SETUP will appear.
‘V’ press the button twice until ‘V’ appears. If you wish to enter a blank space, press the ► Navigation Button [oval 16]. When the desired character appears, press the ► Navigation Button [oval 16] and repeat the process for the next letter. Continue until the desired name is entered, up to 14 characters. When the name is complete, press the Set Button [oval 18] to enter it into the system memory. Repeat for all Inputs where specific Source Names are desired.
When the AVR21EN is configured for 7.1-channel operation, and the SURR BACK line of the SPEAKER SETUP menu is set to SMALL or LARGE, additional modes such as Dolby Digital EX, Dolby Pro Logic IIx and DTS-ES will appear, as they are only available when seven main speakers are present. In addition, some of the modes available in the AVR21EN will not appear unless a digital source is selected and is playing the correct bitstream.
When all settings for the surround setup have been made, press the ▼/▲ Navigation Button [oval 16] so that the cursor is next to BACK TO MAIN ROOM, and press the Set Button [oval 18] to return to the MAIN ROOM SETUP. DTS With DTS selected in SOURCES 1/AUDIO MODE , the selection choices made with the ◄/► Navigation Button [oval 16] on the remote are determined by a combination of the type of program material in use and whether the 5.1- or 7.1- channel configuration is selected in System Configuration.
SURROUND OFF + DSP is selected, you will still have a two-channel presentation, but bass management is applied. You may also select a 5 CH STEREO and 7 CH STEREO mode, depending on how many speakers are available. These two modes feed a two channel presentation to the front left/right and surround speakers, as stereo pairs, with a mix of the left and right channels fed to the center speakers.
your video screen, press the ▼/▲ Navigation Button [oval 16] until the on-screen cursor is pointing to MAIN ROOM SETUP and press the Set Button [oval 18] again. The MAIN ROOM SETUP will appear on-screen. Press the ▼/▲ Navigation Button [oval 16] until the on-screen cursor is pointing to SOURCES and press the Set Button [oval 18] again. Press the ▼/▲ Navigation Button [oval 16] to move the cursor to YES In the ARE YOU SURE YOU WANT TO CHANGE…? screen and press the Set button [oval 18].
LEVEL and then press the ◄/► Navigation Button [oval 16] to enter the setting that delivers the best image to your eyes on the scale of 0 to 100. Noise Reduction: When this setting is turned on, there is a reduction in the video noise that is often present in analog input sources. X-Color Suprression: When this setting is on, there is a reduction in the crosscolor interference that typically appears in composite video sources as moiré in finely detailed objects.
Figure 22 Video Settings 3 Screen Brightness: The changes to this setting are similar to the Brightness control on your display, changing the video level. If circumstances are such that a source has a low signal and appears dark you may wish to change this setting, but be careful not to increase it to the point where the video display is over-driven into clipping or blooming.
Step 2: The EzSet/EQ microphone should be placed in either your usual listening position or, if there is a large seating area, the center of the room, at the listeners’ ear level. You may find it convenient to use a camera tripod for stable placement of the EzSet/EQ microphone at the correct height. The microphone includes a threaded insert on the bottom for tripod mounting.
Figure 24 EzSet/EQ Warning IMPORTANT NOTE: Anyone with hearing that is sensitive to loud noises should leave the room at this point, or use ear protection sufficient to reduce the noise level. Inexpensive foam-style ear plugs, available at most drug stores, may be used to reduce the sound level to a tolerable level.
Step 8: Once EzSet/EQ has been started, you will hear test signals circulate among all of the speakers as the system sets the master volume level, checks for the presence of speakers, sets the distance measurement and calculates delay time settings, sets the output level for each speaker, sets the speaker “size”, and sets the speaker crossover point, and automatically equalizes the frequency response to eliminate any artifacts or reverberation that may occur due to the specific room characteristics, such as
• Speaker Crossover: The measurements and calculations for this test take place at the same time as the test signal is circulated to calculate the levels, and they are used to determine the crossover setting for each speaker in your system to create a seamless transition between the frequencies sent to your main speakers and subwoofer (if available).
IMPORTANT NOTE: Listeners are often confused about the operation of the surround channels. While some assume that sound should always be coming from each speaker, most of the time there will be little or no sound in the surround channels. This is because they are only used when a movie director or sound mixer specifically places sound there to create ambience, a special effect or to continue action from the front of the room to the rear.
EzSet ACTIVATE: To configure system speaker settings, press the ▼/▲ Navigation Button [oval 16] to move the cursor next to: CONFIG AND BASS MGR. Press the Set Button. The SPEAKER CONFIGURATION AND BASS MANAGER screen will appear. (Figure 27) Figure 27 Speaker Configuration Screen Speaker Configuration and Bass Management Begin the speaker setup process by making certain that the cursor is pointing at the FRONT line, which sets the configuration for the front left and right speakers.
When you have completed your selection for the center channel, press the ▼/▲ Navigation Button [oval 16] to move the cursor to SIDE SURROUND. Press the ◄/► Navigation Button [oval 16] to select the option that best describes the surround speakers in your system based on the definitions shown on this page. When SMALL is selected, low-frequency surround channel sounds will be sent to the subwoofer output only.
• If a subwoofer is connected to the AVR21EN, you have the option to have the front left/right main speakers reproduce bass frequencies at all times, and have the subwoofer operate only when the AVR21EN is being used with a digital source that contains a dedicated low-frequency effects, or LFE, soundtrack. This allows you to use both your main and subwoofer speakers to take advantage of the special bass sounds created for some movies. Press ◄/► Navigation Button [oval 16] until SUB (LFE) appears.
Speaker Crossovers To change the setting for any of the four speaker groups, press the ▼/▲ Navigation Button [oval 16] until the cursor is next to the speaker group where you wish to make a change and then press the ◄/► Navigation Button [oval 16] until the desired setting appears. The available choices for low-frequency information to be sent to the subwoofer, rather than to the main speaker channel, are 40Hz, 60Hz, 80Hz, 90Hz, 100Hz, 120Hz and 200Hz.
MAIN ROOM to make other selections and then press the Set Button [oval 18]. To exit setup, Press the Exit Button [oval 17] on the remote. Speaker Distances (Delay) Due to the different distances between the listening position and each speaker position, the amount of time it takes for sound to reach your ears from each channel is different.
With the on-screen cursor pointing to FRONT, press the ◄/► Navigation Button [oval 16] until the distance from the front speakers to the preferred listening position is entered. Next, press the ▼/▲ Navigation Button [oval 16] to move the cursor to CENTER and use the ◄/► Navigation Button [oval 16] again to enter the distance from the main listening position to the center speaker.
When all delay settings made using the menu system have been completed, press the ▼/▲Navigation Button [oval 16] until the cursor is pointing to the BACK TO MAIN MENU line and press the Set Button [oval 18]. REC OUT The REC OUT line gives you the opportunity to select which type of audio signal is directed to the Record Output Jacks associated with VR [square 5], and AUX [square 8]. The default setting is ANALOG, which will send the analog signal from any source to all three sets of analog record outputs.
Screen Type CRT: This setting is optimized for use with displays that use cathode ray tubes (CRTs) to display images. For the purposes of this setting it does not matter if the display is a single tube, direct view CRT television or a three-tube front or rear projector. The default aspect ratio is 4:3, but you may change that setting if desired in the VIDEO MONITOR SETTINGS screen.
Out Aspect Ratio This setting selects between 4:3 and 16:9 aspect ratio as described in Screen Type above. To set OUT ASPEDT RATIO, press the ▼/▲ Navigation Button [oval 16] until the cursor is positioned next to OUT ASPECT RATIO. Press the ◄/► Navigation Button [oval 16] to select the appropriate setting.
Once this time is set and the unit returned to normal operation, the displays will remain on for the time period selected whenever a button is pressed on the front panel or remote. After that time, they will gradually fade out, with the exception of the LED in the Power Button [square 2], which remains on to remind you that the AVR is turned on.
On Screen Status The semi-OSD system places two-line messages at bottom of the video display screen whenever the Volume, Input Source, Surround Mode, Tuner Frequency or any of the configuration settings are changed. The semi-OSD system is helpful in that it enables you to have feedback on any control changes or remote commands using the video display when it is difficult to view the AVR front-panel display. However, you may also prefer to turn these displays off permanently.
The AVR21EN utilizes a unique control system where the external sources connected to the AVR Rear Panel, (Disc 1, Disc 2, Disc 3, AUX, VR, Cable/SAT) are not controlled directly from the AVR21ENR1 Main Room Remote. Instead, the remote outputs proprietary Audioaccess IR commands that are recognized by the AVR21EN and converted to the specific manufacturer’s control codes for the external sources.
Figure 32 Source Control Setup Setup Screen Carrier With the cursor positioned next to CARRIER, press the ◄/► Navigation Button [oval 16] to select the proper setting. Press the Set Button [oval 18]. NOTE: Most IR remotes used with common source components will have a carrier, so YES should be selected as a first test. Some Cable Box remotes do not use a carrier, so if the CARRIER: YES setting doesn’t work, try changing the setting to NO.
Press the ◄/► Navigation Button [oval 16] to select the source type: DVD or CD. Press the ▼/▲Navigation Button [oval 16] to move the cursor next to: BRAND. Press the ◄/► Navigation Button [oval 16] to select the appropriate brand. Press the ▼/▲Navigation Button [oval 16] to move the cursor next to: TRY CODES.
Navigation Button [oval 16] to test all selected device type commands until the unit turns off. When the unit turns off, press the ▼ Navigation Button [oval 16] to move the cursor next to: YES. Press the Set Button [oval 18] to ‘save’ the code group. Press the Exit Button [oval 17] to exit Menu. Press the appropriate Input Selector [oval 4] on the AVR21ENR1 remote to select the source and then press various control buttons, (Play, Stop, Track, numeric functions, etc) to confirm IR codes.
Press the Exit Button [oval 17] to Exit Menu to test the learned codes. Once the appropriate code(s) have been learned and tested, return to the REMOTE CONTROL SETUP 1 screen to configure the next source’s IR codes. Repeat until all sources are setup for IR control. ON-OFF COMM (On-Off Command) On-Off Command has three options. SPF: This setting tells the AVR21EN to look at a specific source’s SPF FLAG-IN Jack [circle 39] on the AVR Rear Panel, to determine ON/OFF Status.
MASTER ON/OFF ENABLED, an IR emitter must be connected to the Control Out ALL Jack [circle 35] on the AVR rear panel and attached to the device being controlled (TV/Projector, Screen, Lights, Curtain) over the IR eye on that device. If more than one emitter is to be used, connect the Control Out ALL Jack [circle 35] to the IR IN on an amplified IR Connecting Block and connect the additional emitter.
Invert Code Press the ▼/▲Navigation Button [oval 16] to move the cursor next to: INVERT CODE. Press the ◄/► Navigation Button [oval 16] to select YES/NO. Most devices will be set to NO. Certain devices, (Sony S-Link, Harman Kardon Remote Control IN) will require a YES setting. Try changing this setting if a specific code selection does not work for a given device. Program Code Press the ▼/▲ Navigation Button [0val 16] so that the cursor is pointed to the PREOGRAM CODE line. Press the Set Button [oval 18].
To continue in setup, press the ▼ Navigation Button [oval 16] to move the cursor next to: BACK TO T/P CODE PROG. Press the Set Button [oval 18]. Press the ▼ Navigation Button [oval 16] again to move the cursor next to: BACK TO T/P CNTL SETUP. Press the Set Button [oval 18]. The TV/PROJ CONTROL SETUP screen will appear. To program SCREEN UP/DOWN, LIGHTING ON/OFF, CURTAIN OPEN/CLOSE, press the ▼/▲Navigation Button [oval 16] to move the cursor next to: BACK TO REM CNTL SETUP. Press the Set Button [oval 18].
SCREEN CONTROL To drop and raise a projection screen with the AVR turn on/turn off functions, press the Menu Button [oval 44] on the remote to bring the MAIN MENU to the screen. Press the ▼/▲ Navigation Button [oval 16] so that the cursor is pointed to the REMOTE CONTROL SETUP line. Press the Set Button [oval 18]. The REMOTE CNTL SETUP 1 screen will appear. Press the ▼/▲ Navigation Button [oval 16] so that the cursor is pointed to GO TO REMOTE CNTL 2. Press the Set Button [oval 18].
Screen Program Code (Automatic) If ON/OFF codes could not be found by Brand in the Manual Mode, try searching by source type in the Automatic mode. In the SCREEN CODE PROGRAM screen, press the ▼/▲Navigation Button [oval 16] to move the cursor next to: AUTOMATIC. Press the Set Button [oval 18]. The SCREEN AUTO PROGRAM screen will appear. The SOURCE will be fixed as selected (SCREEN). Press the ▼ Navigation Button [oval 16] to move the cursor next to: TRY CODES.
Test Screen Code To test the Screen ON/OFF commands the AVR21ENR1 remote must be configured for HT MASTER ON/OFF ENABLED. Press and hold the REM MENU Button [oval 36] on the remote until the Set Button [oval 18] lights red. Press the ▲ Navigation Button [oval 16] TWICE so HT MASTER ON/OFF shows in the remote’s LCD Information Display. Press the Set Button [oval 18]. Press the ▼/▲ Navigation Button [oval 16] until ENABLED appears in the display. Press the Set Button [oval 18].
panel; or press the ON Button [oval 2] on the AVR21ENR1 remote. The AVR should turn ON and the screen should drop. To test OFF, either: press the Standby/ON Button [square 2] on the AVR front panel; or: press the OFF Button on the AVR21ENR1 remote. The AVR should turn OFF and the screen should retract. To test the SCREEN UP/DOWN commands with MANUAL VIA REMOTE, turn the AVR OFF and manually raise the screen.
turns off. When the unit turns off, press the ▼/▲Navigation Button [oval 16] to move the cursor next to: YES. Press the Set Button [oval 18]. This will ‘save’ this code group for ON/OFF control of the lights. If no IR ON/OFF commands were found, see Automatic and Learn, below. If no further programming is required, press the AVR Button [oval 5] on the AVR21ENR1 remote and then the Exit Button [oval 17] to return to normal operation mode.
indicating a function can be selected for learning. Press the ◄ Navigation Button [oval 16] to select LIGHTING POWER ON. When the ON function appears, press the ▼ Navigation Button [oval 16] to position the cursor next to POINT ORIGINAL REM TO AVR DISPLAY PRESS KEY. Press the Set Button [oval 18]. The POINT ORIGINAL… message will start to flash.
To configure the AVR21EN Trigger Out Jack [circle 38] to control Lighting when the Main Room is turned ON: Press the Menu Button [oval 44] on the remote to bring the MAIN MENU to the screen. Press the ▼/▲ Navigation Button [oval 16] so that the cursor is pointed to the REMOTE CONTROL SETUP line. Press the Set Button [oval 18]. The REMOTE CNTL SETUP 1 screen will appear. Press the ▼/▲ Navigation Button [oval 16] so that the cursor is pointed to GO TO REMOTE CNTL 2. Press the Set Button [oval 18].
Invert Code Press the ▼/▲Navigation Button [oval 16] to move the cursor next to: INVERT CODE. Press the ◄/► Navigation Button [oval 16] to select YES/NO. Most devices will be set to NO. Certain devices, (Sony S-Link, Harman Kardon Remote Control IN) will require a YES setting. Try changing this setting if a specific code selection does not work for a given device. Program Code Press the ▼/▲ Navigation Button [oval 16] so that the cursor is pointed to the PREOGRAM CODE line. Press the Set Button [oval 18].
To continue in setup, press the ▼ Navigation Button [oval 16] to move the cursor next to: BACK TO CURTAIN CODE PROG. Press the Set Button [oval 18]. Press the ▼ Navigation Button [oval 16] again to move the cursor next to: BACK TO CURTAIN CNTL SETUP. Press the Set Button [oval 18]. The CURTAIN CONTROL SETUP screen will appear. To program TV/PROJECTOR ON/OFF, DRAPES OPEN/CLOSE, LIGHTING ON/OFF, press the ▼/▲Navigation Button [oval 16] to move the cursor next to: BACK TO REM CNTL SETUP.
Voltage Trigger (Curtain) The Trigger Out [circle 38] on the AVR rear panel can be controlled in two modes: AVR ON/OFF: Simply put, when the AVR turns ON, the Trigger Out [circle 38] outputs a constant +12VDC control voltage. In this case with the Trigger Out [circle 38] being used to open a curtain, the curtain will open as soon as the AVR is turned ON. When the AVR is turned OFF, the Trigger Out [circle 38] drops to 0 VDC, and the curtain closes.
PROGRAMMING THE AVR21ENR1 REMOTE CONTROL To control devices such as the TV/Projector, or a video game or camcorder using the AVR21ENR1 Remote Control the AVR remote must be manually programmed using the remote’s built-in menu system. The process is similar in some ways to how the common source components, (DVD, VR, Cable/Sat) are programmed with the AVR OSD, but remote programming is done with the remote’s menu instead.
6. The next menu screen on the remote (Figure 41) will show the start of the list of available brands. Press the ▼/▲ Navigation Buttons [oval 16] until the brand name of the device you are programming into the remote appears on the lower line of the display and then press the Set Button [oval 18]. Figure 41 NOTE: If the brand name for the product you wish to program does not appear in the list, the codes may still be available, as some manufacturers share codes.
10. When the device being programmed does turn off after a numeric key has been pressed, you must press the Set Button [oval 18] within five seconds to enter the setting into the remote’s memory. After you press the Set Button [oval 18], the top line of the LCD display will read SAVING… and then the word SAVED will flash four times in the center of the bottom line. 11.
while the bottom line reads PLEASE WAIT…. You will also see the transmit icon in the upper right corner of the LCD display’s top line to remind you that the remote is working even though you may not see anything happening to the device being programmed. 7. It will take a few seconds for the remote to send out the first group of commands, after which you will see a new display in the LCD screen, as shown in Figure 45.
12. When pressing one of the numeric keys in Step 10 or 11 causes the device being programmed to turn back on, follow the instructions shown in Figure 47 and press the Set Button [oval 18] within five seconds of the device turning on. After you press the Set button [oval 18], the top line of the LCD display will read SAVING… and then the word SAVED will flash four times in the center of the bottom line. 13.
3. Press the Set Button [oval 18]. The message in the LCD display will change to the LEARN CODE menu (Figure 49). The bottom line will default to the LEARN DEVICE option. Figure 49 Press the Set Button [oval 18]. The message: PRESS DEVICE TO BE PROGRAMMED will appear in the LCD display. Press the remote Input Select Button [oval 4] to which the IR command is to be added. The message: PRESS BUTTON ON ORIGINAL REMOTE will appear in the LCD display.
Figure 52 Press the ▼▲ Navigation Button [oval 16] to change the option in the lower line to TV. NOTE: GAME/CAM and TV are the only two devices that can learn IR commands to any button. To add learn commands to buttons for other sources, see the section: Remote Control Setup/Learn. Press the Set Button [oval 18] to select the device to be programmed. The PRESS BUTTON TO BE PROGRAMMED message will appear in the LCD display. Press the button on the AVR Remote to be programmed.
HT Master (Home Theater Master) The AVR21ENR1 remote ON/OFF buttons have two selectable modes when used after pressing the TV Button. These modes are enabled/disabled in the following instructions. HT MASTER ON/OFF DISABLED: In this mode, after pressing the remote TV Button [oval 6], the remote ON/OFF Buttons [ovals 1, 2] will turn the Main Room Video Display ON or OFF. All other buttons will send TV control functions as configured. (Volume up/down, numeric commands, etc.
remote’s two-line display, it is easier than ever for you to take advantage of the power of macro commands. Recording a Macro To record a macro into the remote’s memory, follow these steps: 1. Press and hold the REM MENU Button [oval 36] for about three seconds while the message HOLD BUTTON FOR 3 SECONDS appears in the remote’s LCD Information Display [oval 3]. Release the button when the red light under the Set Button [oval 18] appears. 2.
button that is being programmed (e.g., the Macro 1 Button [oval 32]) and the indication at the right side of the top line shows the number of macro steps available of 20 possible steps. Following the instructions on the remote’s LCD screen, press the first key you wish to be transmitted in the macro. In our example, we first want the AVR21EN to turn on, so the AVR ON Button [oval 2] should be pressed. Figure 61 8.
2. The remote’s MAIN MENU message will appear in the LCD display and the Set Button [oval 18] will remain illuminated in red. Press the ▲ Navigation Button [oval 16] THREE times so that MACRO appears on the bottom line of the LCD screen. Press the Set Button [oval 18] to enter the macro menu branch. 3. At the next menu screen, press the ▼/▲ Navigation Button [oval 16] until the bottom line in the remote’s LCD display reads ERASE A MACRO.
this example, we will read back Macro 1, created in a previous section. When the name of the macro to be read appears, press the Set Button [oval 18]. Figure 66 5. As soon as the Set Button [oval 18] is pressed, the first two steps in the macro will appear in the remote’s LCD screen. You may then use the ▼/▲Navigation Button [oval 16] to step up or down through the list of commands stored as the macro. As you read the display, you will see Input Selector Buttons [oval 4] appear in brackets, (e.g., [AVR]).
4. When the remote has been totally reset and returned to the factory default condition, a REMOTE RESET COMPLETE message will appear (Figure 69) briefly, and then the remote will return to normal operation. Figure 69 Additional Notes on Configuring and Operating the Remote • When the remote is being programmed, it will automatically time-out if no button is pressed within a thirty second period.
• When any button is held for more than thirty seconds, the LCD will turn off and the remote will stop transmitting the codes to conserve battery life. MAIN ROOM OPERATION Basic Operation Once you have completed the initial setup and configuration of the AVR21EN, it is simple to operate and enjoy.
The sleep time will be displayed in the AVR Lower Display Line [square 34] while Sleep Time is being set. The front-panel display will dim to half brightness when the Sleep function is programmed. To cancel the Sleep function, press and hold the Sleep Button [oval 33] until the information display returns to normal brightness; and the words SLEEP OFF appear in the AVR Lower Display Line [square 34]. When the programmed sleep time has elapsed, the unit will turn off.
conversion and it mutes the unused input jacks to prevent unwanted noise from interfering with system performance. ■ The 6 CH DVD AUDIO input should be used when the BSR (7.1) and BSL (7.1) inputs are NOT in use and the source device does NOT have its own internal bass-management system. When this input is in use, the analog source is converted to digital so that you may use the same bass management options for the direct input as you do with all other outputs.
Video Processing The AVR21EN features unique combination of video scaling and processing options that are available when the unit is connected to a “digital ready” or HD capable display device. Thanks to DCDi (Directional Correlation Deinterlacing) by Faroudja and a series of video parameter settings that may be set and stored individually for each video input source, the AVR21EN provides the ultimate in video, as well as audio reproduction.
The Dolby Digital, Dolby Digital EX, DTS 5.1, DTS-ES Matrix and DTS-ES Discrete modes may only be selected when a digital input is in use. In addition, when a digital source is present, the AVR21EN will automatically select and switch to the correct mode, regardless of the mode that has been previously selected. For more information on selecting digital sources, see the Digital Audio Playback section below.
Logic 7 Cinema Logic 7 Music Logic 7 Enhance DTS Neo:6 Cinema DTS Neo:6 Music Theater Small Concert, Medium Concert Dolby VirtualSpeaker Reference Wide 5-Channel Stereo 7-Channel Stereo Surround Off (Stereo) Dolby Headphone DH1 DH2 DH3 BP Exclusive to Audioaccess for receivers, Logic 7 is an advanced mode that extracts the maximum surround information from either surround-encoded programs or conventional stereo material.
DTS DTS is a digital audio system capable of delivering 5.1 or 6.1 discrete or matrix sound field reproduction. Although both DTS and Dolby Digital are digital, they use different methods of encoding the signals, and thus they require different decoding circuits to convert the digital signals back to analog. DTS-encoded soundtracks are available on select DVD and LD discs, as well as on audio-only DTS discs.
Dolby Digital decoding. When the unit senses PCM data from CDs or LDs, you may select any of the standard surround modes, such as Dolby Pro Logic II or Logic 7. Since the range of available surround modes is dependent on the type of digital data that is present, the AVR21EN shows you what type of signal is present. This will help you to understand the choice of modes. When a digital source is first detected, the AVR21EN will display a message to indicate the type of bitstream being received.
Digital signal with a 3/1/0 or 2/0/0 signal is detected, you may select any of the Dolby surround modes. When DS-OFF appears as a message, it indicates that there is no Dolby Surround data flag in the audio bitstream. Similarly, EX-OFF indicates that there is no Dolby Digital EX data flag. In the case of a DS-OFF message, you may manually select a Dolby Pro Logic mode to add a multichannel presentation to the stereo material.
Speaker/Channel Indicators In addition to the bitstream indicators, the AVR21EN features channel-input indicators that show how many channels of digital information are being received and/or whether the digital signal is interrupted. Figure 73 Speaker/Channel Input Indicators These indicators are the L/C/R/LFE/SL/SR/SBL/SBR letters that are inside the center boxes of the Speaker/Channel Input Indicators [square 35] on the front panel.
The Night Mode may be engaged when a Dolby Digital DVD is playing by pressing the Night Mode Button [oval 34] on the remote. Next, press the ▼/▲ Navigation Button [oval 16] to select either the middle range or full compression versions of the Night mode. To turn the Night mode off, press the ▼/▲ Navigation Button [oval 16] until the message in the lower third of the video display and in the AVR Lower Display Line [square 34] reads NIGHT MODE OFF.
appear. This is normal and does not indicate a problem with either the AVR21EN or the source machine. The AVR21EN will return to digital playback as soon as the data is available. • Some source devices, particularly cable set-top boxes, will switch back and forth between digital and analog audio outputs, depending on the channel being watched.
4. Stations may also be tuned directly in either the automatic or manual mode. To enter a station’s frequency directly, first select the AM or FM band as desired be pressing the AM/FM Button [square 10, oval 37]. Next, press the Direct Button [oval 12] on the remote. Within five seconds of when DIRECT IN scrolls in the AVR Upper Display Line [square 33], enter the station frequency by pressing the Alphanumeric Keys [oval 46].
• The Front-Panel Coaxial 3 [square 16] and Game/Cam Jacks [squares 19, 20, 22, 23] may be configured for use as outputs, allowing connection to a recorder, when the steps shown in the section Front-Panel Connections below are followed. • Please obey the copyright restrictions on any material you copy. Unauthorized duplication of copyrighted materials is prohibited by law.
If you are using a disc with test signals or an external signal generator as the source used when the output levels are being trimmed, you must use the Optimizer Mic. Follow the instructions in AVR21EN Configuration/Using EzSet/EQ. Once the reference level has been set, on the AVR front panel, press the Channel Select Button [square 28] and FRONT L LEVEL will appear in the AVR Lower Display Line [square 34].
Front Panel Settings The front-panel information display will normally stay on at full brightness as long as the AVR is ON. In some situations, such as a darkened theater room, the light from the display might be distracting. The display can be set to fade out and turn off from 3-9 seconds after a remote or front-panel button press. The display will illuminate full brightness when a remote or front panel button is pressed.
To set on-screen status, press the remote Menu Button [oval 44] to bring the MAIN MENU to the screen. Press the ▼/▲ Navigation Button [oval 16] so that the cursor is pointed to the MAIN ROOM SETUP line. Press the Set Button [oval 18]. Press the ▼/▲ Navigation Button [oval 16] so that the cursor is pointed to the ADVANCED line. Press the Set Button [oval 18]. Press the ▼/▲ Navigation Button [oval 16] so that the cursor is pointed to the ON SCREEN STATUS line.
MAIN ROOM TROUBLESHOOTING GUIDE SYMPTOM Unit does not function when Main Power switch is pushed CAUSE • No AC Power Display lights, but no sound or picture • Intermittent input connections • Mute is ON • Volume control is down • Display brightness is turned off Unit turns on, but front panel display does not light up No sound from any speaker; LED in power switch is red No sound from surround or center speakers • Amplifier is in protection mode due to a possible short • Amplifier is in protection mode
Processor Reset In the rare case where the unit’s operation or the displays seem abnormal, the cause may involve the erratic operation of the system’s memory or microprocessor. To correct this problem, first unplug the unit from the AC wall outlet and wait at least three minutes. After the pause, reconnect the AC power cord and check the unit’s operation. If the system still malfunctions, a system reset may clear the problem.
APPENDIX SYSTEM DEFAULTS The three tables in this section show the factory default settings for the Audio and Video Inputs, Video Sources and Video Display Aspect Ratios. These tables give you the complete picture on the AVR21EN’s initial settings. You may then decide whether any item needs to be changed so that it is more appropriate for your specific installation. Any of the settings shown may be changed as shown in the pages of the AVR21EN Configuration section of this manual.
WORKSHEET 1: SYSTEM SETTINGS FEATURE System Configuration Lip Sync Record Out Screen Type Out Aspect Ratio Component Out HDMi Enhance HDMi Audio Front Panel Timeout Front Panel Brightness Power On Vol OFF/ON Power On Vol LVL On Screen Status Main Menu Timeout SETTING WORKSHEET 2: SPEAKER SETTINGS SPEAKER POSITION SIZE X-OVER DISTANCES LEVEL LEFT LEVEL RIGHT LEVEL CENTER/ SUB Front Center Side Surround Back Surround Subwoofer Bass Manager WORKSHEET 3: INPUT SETTINGS FEATURE DISC 1 DISC 2 DISC 3
AVR21EN SPECIFICATIONS Audio Section Stereo Mode Continuous average power (FTC): Seven-channel surround modes, power per channel, all channels driven: 100 Watts per channel, 20Hz–20kHz,@ <0.1%THD, both channels driven into 8 ohms 70 Watts per channel @ <0.
Dimensions (H x W x D) Product: Shipping: Weight Product: Shipping: 6-5/8"x 17-3/8"x 17-1/8" (168mm x 440mm x 435mm) 10-5/8"x 22-5/8"x 21-5/8" (270mm x 575mm x 549mm) 23.1 lb (10.5kg) 34.8 lb (15.8kg) Depth measurement includes knobs, buttons and terminal connections. Height measurement includes feet and chassis. All features and specifications are subject to change without notice. Audioaccess and Logic 7 are registered trademarks of Harman International Industries, Incorporated.
MULTIROOM COMPONENTS AVH21 FRONT PANEL FEATURES Figure 74 AVH21 Front Panel 1. 2. 3. 4. 5. 6. Source Video Bypass Outputs Keypad/Zone Video Outputs Camera Video Bypass Outputs AVH21 Mounting Flange KP21 Keypad Terminals Expansion/Auxiliary Keypad Terminal AVH21 FRONT PANEL FEATURE DESCRIPTIONS 1.
digital audio distribution when using multiple AVH21’s for additional zones in expanded systems. AVH21 REAR PANEL FEATURES Figure 75 AVH21 Rear Panel 4. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16.
9. Power IN: 1, four position plug-in terminal for connection to WPS21 Power Supply Hub AVH21 A/V Hub Power Terminal [rectangle 5] for DC voltage to power the AVH21 Hub and connected keypads. 10. Door 1 12/24VDC Latching Trigger Output: 1, two position plug-in terminal connects to a voltage activated door lock. Selectable 12 or 24 VDC output allows remote control of voltage activated door locks. 11.
AVH21 TOP FEATURES Figure 76 AVH21 Top Panel 4. 17. 18. 19. AVH21 Mounting Flange AVH21 Status Panel Hub Configuration Switch Mounting Screw Holes AVH21 TOP PANEL FEATURE DESCRIPTIONS 4. AVH21 Mounting Flange: 2, chassis metal extensions, one on either side of the AVH21 used for vertical installation to structured wiring panels or wall surfaces using mounting screw holes. The mounting flange also creates a space under the AVH21 for organized wire and cable management. 17.
AVH21 STATUS PANEL FEATURES Figure 77 AVH21 Status Panel Label 20. 21. 22. 23. 24. 25. 26. 27. 28. Reset Button Power Indicator Hub Connection Indicator Expansion Hub Connection Indicator Uplink Activity Indicator Keypad Connection Indicators Door 1 Trigger Output Indicator (Open/Close A) Door 2 Trigger Output Indicator (Open/Close B) Hub Configuration Switch AVH21 STATUS PANEL FEATURE DESCRIPTIONS 20.
Upper ‘A’ LED [pentagon 26] will turn off and the Lower ‘A’ LED [pentagon 26] will turn on constant. 27. Door 2 Trigger Output Indicator (Open/Close B): 2, green LED’s illuminate to indicate Door 2 Trigger activity. The Lower ‘B’ LED [pentagon 27] will normally be illuminated indicating an open circuit. When the Door 2 Trigger receives an OPEN command from either a KP21 Keypad or KP21R remote, the relay will close for approximately 3 seconds.
5. AVH21 A/V Hub Power Terminal: 1, four position plug-in terminal connects to Power In [pentagon 9] on an AVH21 A/V Hub to provide DC voltage to the A/V Hub and connected KP21 Keypads. 6. AC Power Cord Jack: Connect the AC power cord to this jack when the installation is complete. To ensure safe operation, use only the power cord supplied with the unit. If a replacement is required, it must be of the same type and capacity. WPS21 TOP PANEL FEATURES Figure 79 WPS21 Top Panel Features 3.
WPS21 STATUS PANEL FEATURES Figure 80 WPS21 Status Panel Label 7. Power Indicator 8. Keypad Power Status Indicators 9. A/V Hub Power Status Indicator WPS21 STATUS PANEL FEATURE DESCRIPTIONS 9. Power Indicator: 1, red LED illuminates to indicate WPS21 has AC power. 10. Keypad Power Status Indicators: 7, green LED’s, illuminate to indicate active KP21 Keypad Power Terminals [rectangle 4]. LED will turn off if KP terminal fuse has blown. 11.
KP21 FRONT PANEL FEATURES Figure 81 KP21 Front Panel (Bezel Removed) 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. 21.
2. Page/Monitor Microphone: 1, miniature microphone, allows whole-house paging, group paging, talking between rooms and monitoring audio in a selected room via W.H.E.N. Multiroom Link connections. 3. Keypad/Zone/System Power ON/OFF Button: 1, backlit button turns the local keypad/zone ON when the system is active in other zones. When system is OFF, this button will activate the AVR21EN, all common source components and the local zone. When zone is active, the power button brightens to full illumination.
13. LCD Information Display: 1, 3 1/4” backlit LCD, displays A/V Entertainment, Paging, Monitor, Setup, Wakeup, Sleep and Door Lock menus and hard button control functions. Time, Day, and zone volume are also shown. The LCD has three selectable backlight colors (that corresponds to the hard button backlighting) and adjustable backlight time out. 14. Volume Down Button: 1, backlit button, adjusts zone/keypad volume down when pressed. 15.
KP21 REAR PANEL FEATURES Figure 82 KP21 Rear Panel (Bezel Attached) 1. 5. 22. 23. 24. 25. 26. 27. 28. 29. 30. 31. 32. Keypad Mounting Screw Holes Bezel Snap Tab IR IN Terminal AVH Hub Terminal Speaker Terminal Keypad Address DIP Switch (Side) Zone Right Channel Preamp Output Zone Left Channel Preamp Output Zone/Keypad Amplifier Local Source Right Channel Input Local Source Left Channel Input Power Terminal Keypad Bezel KP21 REAR PANEL FEATURE DESCRIPTIONS 1.
23. AVH Hub Terminal: 1, RJ45 jack connects to a KP21 Keypad Terminal [pentagon 5] on an AVH21 A/V Hub. This connection provides two-way communication between the keypad and AVH21 Hub for zone/system control. It also receives digital audio data to the keypad from the AVH21 for audio from common source components as selected by the zone keypad or a local IR remote. 24. Speaker Terminal: 1, four position screw-terminal provides connection to local zone speakers. 25.
KP21R REMOTE CONTROL FEATURES 1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14. 15. 16. 17. 18. 19. 20. 21. 22. 23. 24. 25. 26. 27. 28. 29. 30. 31. 32. 33. 34. 35. 36. 37. 38. 39. 40. 41. 42. 43. 44. 45. 46. 47. 48. 49. 50.
KP21R REMOTE CONTROL FEATURE DESCRIPTIONS NOTES: • The function names shown here are each button’s function when used with a KP21 Keypad and AVR21EN Controller (System). Most buttons have additional functions when used with other devices, and some of these functions may be assigned to different buttons, depending on which device was selected.
7. Disc Direct: Press this button when a disc changer is in use to directly enter a disc number. After pressing this button, press the appropriate Alphanumeric Keys [triangle 43] to select a disc. 8. Disc Memory Button: ??? ??? 9. Direct/List Select Button: Press this button when the tuner is in use to directly enter a station’s frequency, or when a CD is in use to directly enter a track number. After pressing this button, press the appropriate Alphanumeric Keys [triangle 43] to select a station or track.
19. Record/Stop/Pause Transport Controls: These buttons are used when the remote is programmed for a compatible DVD, CD or tape player. Pressing these buttons will transmit a stop, record, or pause command, according to the capabilities of the player being controlled. 20. Status/Setting Buttons: This button has different functions, depending on which device is in use. Press it to display an external DVD recorder’s status. For DVR’s and game consoles, this button performs the Back function.
33. Remote Menu/PIP Channel Up Button: In System mode, this button accesses the menu system for the remote control, enabling you to program product codes, record macros and perform other functions. 34. Top Menu/PIP On/Off/PIP Swap/AM/FM Button: When one of the AVR21EN internal Tuners has been selected, or when using an external tuner press this button once to toggle Tuner band. If an FM station is selected, the tuner will toggle to AM. Press the button again to return to FM. 35.
41. Menu/Info Button: This multipurpose button has a different function depending on the source in use. In DVD mode, this button accesses the menu on the current disc, enabling you to select the main feature or accompanying featurettes for playback or make other selections, depending on how the disc is programmed. For cable and satellite, this button will activate an on-screen menu. 42.
KP21R ZONE REMOTE FUNCTION LIST Figure 84 KP21R Button Locations 156
No.
MULTIROOM INSTALLATION & SETUP Installing W.H.E.N. System Components W.H.E.N. allows unprecedented flexibility in system design for incorporating whole-house A/V distribution and control and home theater. For the purpose of detailing the options, the Multi-Zone sections will be broken down into three groups: Main Room, Three Zone System and Hub System. There are critical differences in system components and connections with these different options, so each will be detailed separately.
Figure 86 Typical Three Zone System 159
THREE ZONE SYSTEM Main Room The AVR21EN and all common source components and speakers should be installed, connected and setup as described in the sections: Pre-Wire/Main Room, and Main Room Installation and Setup. Remote Rooms Keypads In addition, a CAT5e should be pulled from the KP21 Keypad location in each remote zone (up to two) to the AVR21EN for control, audio and data.
Figure 87 Typical Hub System 161
HUB SYSTEM Main Room The AVR21EN and all common source components and speakers should be installed, connected and setup as described in the sections: Pre-Wire/Main Room, and Main Room Installation and Setup. Hub Installation In Hub Systems, the AVH21 A/V Hubs and WPS Power Supply Hubs are always used in pairs. (One each AVH21 and WPS21.) The recommended positioning for these pairs is side by side.
AVH21 CONFIGURATION Whether using one AVH21 or three, the Hubs need to be configured for ‘Hub Number’ and ‘Zone Group’ identification. (This is not the same as the Entertainment, Wake-Up and Sleep Groups that are configured in the ZONE SETUP Menu.) This allows the system management software to keep track of which zones are doing what. The Hub Configuration Switch [pentagon 28] on the AVH21 Top Panel identifies each Hub and its Zone Group.
Figure 90 Multiple Hub Power Connections 164
Uplink/Multiroom Link 1. Using CAT5e cable, properly terminated with RJ45 connectors, connect the Multiroom Link Terminal [circle 30] on the AVR21EN to the Uplink Terminal [pentagon 16] on the AVH21 as shown in Figure 91. 2. In larger systems using multiple Hubs, complete step 1 above by connecting the Multiroom Link Terminal [circle 30] on the AVR21EN to the Uplink Terminal [pentagon 16] on AVH21 #1 as shown in Figure 91.
Keypad Connections 1. Using CAT5e cable properly terminated with RJ45 connectors, connect the cables to the appropriate KP21 Keypad Terminals, KP 1-7 [pentagon 5] on the AVH21. As shown in Figure 92. Confirm proper connection by zone (Keypad number). Improper connection of the wrong keypad to the wrong terminal will cause operational errors. 2. In larger systems using multiple Hubs, repeat step 1 for all keypad connections to AVH21 #s 1,2 and 3.
Source Video In 1. Using RG6 Quad shield coaxial cable terminated with male F connectors, connect each of the Video Source Out Terminals [circle 37] on the AVR21EN Rear Panel to the appropriate Source Video Input [pentagon 8] on the AVH21 as shown in Figure 93. 2. In larger systems, complete step 1 above by connecting the Video Source Outs [circle 37] on the AVR21EN to the appropriate Source Video Inputs [pentagon 8] on AVH21 #1 as shown in Figure 93.
Zone (KP) Video Out 1. Using RG6 quad shield coaxial cable terminated with male F connectors, connect the appropriate KP Video Output 1-6 Terminal [pentagon 2] on the AVH21, as shown in Figure 94, to the appropriate zone 1-6 video display composite video input. NOTE: The AVH21 only has video outputs for zones 1-6. Confirm proper connection by zone (Keypad number). Improper connection will cause operational errors such as misrouted video signals. 2.
3. Connect the plug-in connector to the appropriate Door 1 Terminal [pentagons 10, 11] on the AVH21 and connect and terminate the door lock end as appropriate. NOTE: Door 1 relays should not be paralleled with Door 2 relays. 4. If using the +/- Terminal [pentagon 10], set the 12V/24V Switch [pentagon 12] to the proper position. 5. In larger systems using multiple AVH21’s, the Door 1 terminals can be used to activate different door locks in different areas.
25] on the side of the KP21. There are 20 address configurations.
AUX In (Local Source In) This connection allows the audio from a local source such as a CD/DVD player, DVR, cable/satellite receiver or Video Game to be played through the KP21 amplifier and local room speakers. 1. Using shielded stereo audio cable, strip approximately ¼” and twist the ends until there are no loose strands that can cause shorts. 2.
Figure 97 KP21 PREOUT Connections Speakers 1. Using 16AWG two-conductor stranded wire, strip approximately ¼” and twist the ends until there are no loose strands that can cause shorts. 2. Insert the twisted ends into the appropriate slots on the R+/R- and L+/L- speaker (SPK) Terminals [hexagon 24] on the KP21 rear panel as shown in Figure 98, and tighten with a small blade screwdriver. Pull the wire slightly to confirm connection. Confirm polarity. 3. Terminate and connect speaker ends as appropriate.
2. Connect the RG6 to the composite video input on the local zone video display. Confirm proper AVH21 zone KP Video Output [pentagon 2] connection. Connecting An External IR Sensor In some installations, the keypad will not be mounted on the same wall as the speakers and video display, the focal point of the room. In fact, the keypad may be mounted behind the seating area, making use of the KP21R remote control a bit awkward.
ZONE SETUP With all system components installed and connected, the system will function to its default settings. That is, a KP21 can turn the system on, select and control sources and adjust volume, in addition to some other basic functions. Figure 100 Main Menu There are other, more advanced, system functions that require setup, using the same On-Screen Menu that was used to set up the Main Room, given the use and configuration of every system is different. To enter the ZONE SETUP mode: 1.
4. Using the ▼/▲ Navigation Button, position the cursor next to MONITORING. Using the ◄/► Navigation Button [oval 16] select YES to able to listen to other zones using the KP21 builtin microphones and/or view activity in those zones if equipped with cameras, or NO if this function is not required. 5. Using the ▼/▲ Navigation Button [oval 16], position the cursor next to WAKE-UP.
6. To exit setup and return to system mode, press the Exit Button [oval 17]. Figure 103 Name Paging Groups Screen Name Paging Groups Paging Groups are combinations of different zones that can be selected at different times for Paging. Some typical examples would be paging groups consisting of all bedrooms, just the children’s bedrooms or a group including the living room, family room and dining room.
Figure 104 Name Entertainment Groups Screen Name Entertainment Groups Entertainment Groups allow multiple zones to be turned on and off together using the Party Mode control. This feature is desirable for parties, to easily be able to select background music through common areas. The zones within the groups will turn on, and play the same source. The zones within the groups can be configured to each turn on to the same source, different sources or the last source selected in each zone.
This section names the Wake-Up Groups. Building the groups will be done in a later section. To name Wake-Up Groups: 1. From ZONE SETUP PAGE 1, with the cursor next to NAME WAKE-UP GROUPS, press the Set Button [oval 18]. The NAME WAKE-UP GROUPS screen will appear. (Figure 105) 2. Press the ▼/▲ Navigation Button [oval 16] to position the cursor next to NAME. Press the Set Button. A white rectangle will flash to the right of NAME: indicating that the remote can be used to enter the letters for the group name.
4. Repeat steps 2-3 above until the Sleep Group Name has been spelled out. A Group Name can have up to 12 letters. Press the Set Button [oval 18]. This will store the name and return the cursor to the arrow next to NAME. 5. To name additional groups, press the ▼/▲ Navigation Button [oval 16] to position the cursor next to GROUP. Press the ◄/► Navigation Button [oval 16] to select another group. 6. Repeat steps 2-4 until all desired Wake-up Groups have been named. Up to 8 Sleep Groups can be created.
8. Repeat steps 2-4 until all desired Cameras have been setup. Up to 7 Cameras can be configured, matching the number of camera inputs on the AVH21’s. To exit setup, press the Exit Button [oval 17]. To continue Zone Setup, position the cursor next to BACK TO ZONE SETUP and press the Set Button [oval 18]. ZONE SETUP PAGE 1 will appear. Figure 108 Name Doors Screen Name Doors Naming doors populates the KP21 Keypad Door sub-menu with names of the door options for Talk and Open.
Figure 109 Zone Setup Page 2 Keypad Setup By Number Keypad Setup configures each keypad (zone) for how each keypad will interact with the rest the system. This setup determines which groups, if any, a zone will be a part of. If a zone has a video camera in it, that camera will be ‘assigned’ in this setup for the purpose of Zone Video Monitoring from other zones. Doorbell, Talk and Open functions are also configured in this section.
To name Zones: 1. In SETUP BY NUMBER PAGE 1, press the ▼/▲ Navigation Button [oval 16] to position the cursor next to NAME. Press the Set Button [oval 18]. A white rectangle will flash to the right of NAME: indicating that the remote can be used to enter the letters for the zone name. 2. Using either the ▼/▲ Navigation Button [oval 16] or the Alphanumeric Buttons [oval 46], enter the first letter for the group name. (i.e. KITCHEN).
turn on to their preset levels or the last level set as determined in zone setup. Each zone will retain its own volume, mute, source select and power controls so a zone within a group can ‘opt out’ at any time by selecting another source or turning off. It is not necessary to set an Entertainment Group for a given zone, so if the preference is have a zone not be included in any Entertainment Groups, select: NONE. To select Paging Group: 1.
Keypad: This option allows the user to change Wake-Up Group or Sleep Group Settings for the specific keypad being configured. Changes will not affect any other keypad in the Group and Local Wake and Sleep Settings can be configured independent of Group Settings. Group: This option allows the user to block Wake-Up Group or Sleep Group Settings for the specific keypad being configured by pressing DISABLE TIMER on the keypad. Changes will not affect any other keypad in the Group.
2. Using the ◄/► Navigation Button [oval 16], set the option for the zone being configured: YES, NO, ONLY IF ON, ONLY IF OFF. To exit setup, press the Exit Button [oval 17]. To continue Zone Setup, position the cursor next to MONITOR THIS ZONE and continue to the next section. Monitor This Zone This setting determines whether or not a zone can be ‘listened to’ using the keypad microphone or ‘viewed’ if the zone being configured has a local video camera installed.
Door Answer This setting will determine whether the zone being configured will have the ability to talk to a selected two-way door panel. When the DOOR button is pressed in the KP21 Keypad Main Menu, a list of available Doors will appear. Selecting a given door then gives the option to TALK to the door panel or OPEN the door lock with an associated AVH21 Door Relay.
1. In the SETUP BY NUMBER PAGE 3 screen, press the ▼/▲ Navigation Button [oval 16] to position the cursor next to DOOR OPEN. 2. Using the ◄/► Navigation Button [oval 16], select the setting for the zone being configured: ENABLED or DISABLED. Wake-Up Group This setting assigns the zone being configured to a Wake-Up Group. A Wake-Up Group is a group of zones that have been configured to turn on at a specific time, to a specific source, at a specific volume, for a pre-set duration.
Wake-Up Time This setting assigns the time that the group being configured will turn on. This setting affects all zones in the group. To set Wake-Up Time: 1. In the WAKE-UP SETUP 1-1 screen, press the ▼/▲ Navigation Button [oval 16] to position the cursor next to WAKE-UP TIME 1. Press the Set Button [oval 18]. The HOUR field will start to flash. 2. Using the ▼/▲ Navigation Button [oval 16], select the HOUR that the group being configured is to turn ON. 3. Press the ► Navigation Button [oval 16].
Figure 114 Custom Wake-Up Time 1 4. With the cursor positioned next to MON, press the ◄/► Navigation Button [oval 16] to set YES/NO. YES will have the group wake-up on Mondays, NO will not have the group wake-up on Mondays. When MON has been configured, press the ▼/▲ Navigation Button [oval 16]. Press the ▼ Navigation Button [oval 16] to move to the next day. Press the ▲ Navigation Button [oval 16] to move to the previous day. 5.
Wake –Up Group Reference only. Not configurable in this screen. Volume Setting This setting configures the volume that all zones in the group being configured will turn on at. Consider the use of Wake-Up Groups when setting this level. Wake-Up for alarm clock purposes should be loud enough to wake someone up but without shocking them or disturbing other zones. A Wake-Up Group set for dinner-time background music should be set as exactly that…background music. To configure Volume Setting: 1.
Figure 116 Sleep Setup 1-1 Sleep Setup 1-1 This sub-menu sets the parameters for each Sleep Group. These setting affect the entire group, but do not affect manual Sleep settings set from the zone keypads. Sleep Group This indicates the Sleep Group being configured. Sleep Group is not selectable in this screen. The Group is selected in the SET-UP BY NUMBER PAGE 3 screen on the SLEEP GROUP: line. To select a Sleep Group: 1.
1. In the SLEEP SETUP 1-1 screen, press the ▼/▲ Navigation Button [oval 16] to position the cursor next to SHUT DOWN. 2. Using the ◄/► Navigation Button [oval 16], set the length of time in minutes that the group being configured is to stay on after the configured SLEEP TIME. Select INSTANT to immediately turn the group off when the Sleep Time has been reached. When This setting will configure which day or days of the week the group being configured will Sleep.
2. Using the ◄/► Navigation Button [oval 16], select the source that the group being configured is to switch to: LAST, LOCAL, DISC 1, DISC2, DISC 3, RADIO 1, RADIO 2, A/V/AUX, VIDEO RECORDER, CABLE/SAT. 3. To continue Setup, press the ▼/▲ Navigation Button [oval 16] to position the cursor next to GO TO SLEEP 1 PAGE 2. Press the Set button [oval 18]. The SLEEP SETUP 1-2 screen will appear. (Figure 118) Figure 118 Sleep Setup 1-2 Sleep Group Reference only. Not configurable in this screen.
Buttons [oval 16] to review Setup Pages and Settings. Make changes as necessary. Refer to previous instructions. Confirm system functions from zones using keypads. To exit menu and return to system mode, press the Exit Button [oval 17]. Keypad Setup By Name Keypad Setup By Name, allows zone configuration when searching by zone name. The Keypad Number is assigned by the system given which KP 1-20 Terminal [pentagon 5] a keypad is connected to on an AVH21.
Figure 120 System Settings Page 1 Figure 121 System Settings Page 2 If a system only has one AVH21 A/V Hub, the Settings screens should appear as shown in Figures 120 & 121. The values associated with AVH Hubs 2 & 3 will appear as shown in Figure 121, indicating no connection.
20 that are communicating properly will be shown on screen. If there are keypads in the system that do not appear, check to be sure they are powered up from the WPS21 Power Hubs and that they are properly connected via CAT5e to the AVH21 Hubs. Figure 122 System Test Screen To Run System Test: 1. In the Main Room, with the AVR21EN and video display ON, using the AVR21ENR1 remote, press the AVR Button [oval 5]. 2. Press the MENU Button [oval 44]. The MAIN MENU will appear. 3.
4. With the cursor next to RESTART NETWORK, press the Set Button [oval 18]. The RESTART NETWORK screen will appear. (Figure 123) 5. Press the ▼/▲ Navigation Button [oval 16] to place the cursor next to YES. Press the Set Button [oval 18]. The menu will automatically return to the DIAGNOSTICS screen. 6. To manually return to DIAGNOSTICS, without restarting, position the cursor next to BACK TO DIAGNOSTICS, press the Set Button [oval 18]. 7. To return to system mode, press the Exit Button [oval 17].
4. LOCAL 1 will appear in the LCD display. (Figure 126) Press the ▼/▲Navigation Button [triangle 13] to scroll to TV/COMBO. Press the Set Button [triangle 15]. Figure 126 5. In the next menu screen, press the ▼/▲ Navigation Button [triangle 13] to scroll to the type of device being controlled. The choices are: TV, TV/VCR and TV/DVD/VCR. Press the Set Button when the correct device appears. Manual Program 6.
9. After you press and release the number key, watch the device being programmed to see whether it turns off. As shown in the instructions that will appear on the next menu screen (Figure 130), if your device has turned off, press the Set Button [triangle 15], and then skip to Step 10. If the unit does not turn off, proceed to the next step. Figure 130 9.
2. Press and hold the REM MENU Button [triangle 33] for about three seconds while the message: HOLD BUTTON FOR 3 SECONDS appears in the remote’s LCD Information Display [triangle 3]. Release the button when the red light under the Set Button [triangle 15] turns on. 3. The remote’s MAIN MENU message will appear in the LCD display and the Set Button [triangle 15] will remain illuminated in red. Press the Set Button [triangle 15] to begin the process of selecting a device and locating the proper remote codes.
Figure 133 9. If the device being programmed does turn off after following the instructions in Step 7, you will need to verify the code set by pressing the Alphanumeric Keys [triangle 43] in sequence, as instructed in Figure 134. Point the remote at the device being programmed, and press the “1” Button [triangle 43] to see whether the device turns back on. Figure 134 10. After pressing and releasing the “1” Button [triangle 43], check to see whether the device has turned back on.
The process requires that both the device’s original remote and the KP21R remote be available. Before pressing any buttons on either remote, place them so that the IR transmitter on the remote from the device to be programmed is facing the Infrared Lens [triangle 50] on the KP21R remote. The two remotes should be no more than an inch apart and there should not be any direct sunlight or other bright light source near the remotes. Learn Device 1.
2. The remote’s MAIN MENU message will appear in the LCD display and the Set Button [triangle 15] will remain illuminated in red. Press the ▲ Navigation Button [triangle 13] once so that LEARN CODE appears on the bottom line of the LCD screen, as shown in Figure 137. Figure 137 3. Press the Set Button [triangle 15]. The message in the LCD display will change to the LEARN CODE menu (Figure 138). The bottom line will default to the LEARN DEVICE option. Figure 138 4.
Figure 140 7. If the message shown in Figure 140 appears in the display, press the Set Button [triangle 15] to try programming the button again. When the remote prompts you to press and hold the key on the original remote again by showing PRESS KEY ON THE ORIGINAL REMOTE in the display, immediately press the button on the source remote again. To avoid another failed attempt, make certain that the windows on the two remotes are facing one another. 8.
Figure 143 4. The next display screen (Figure 144) is where you select the button that will be used to recall the macro. The choices are one of the three discrete Macro Buttons, M1, M2, M3 [triangle 29]. Press the ▼/▲Navigation Button [triangle 13] until the name of the button you wish to program the macro into is shown.
Figure 147 9. For our example, we first want the KP21R Power On button pressed, followed by the TV Power On button. To do that, press the buttons in this order: • DISC 1 [triangle 4] • Power On [triangle 2] • TV [triangle 5] • Power On [triangle 2] As each button is pressed to enter it into the macro, you will see the button names appear and then scroll up on the LCD display as your confirmation of the key entry.
4. The next display screen (Figure 149) is where you select which macro will be erased. Press the ▼/▲ Navigation Button [triangle 13] until the number of the macro you wish to erase appears. For this example we will erase Macro 1 created in the previous section. When the name of the macro to be erased appears, press the Set Button [triangle 15]. Figure 149 5. The word ERASED will flash four times in the bottom line of the remote’s LCD display, and then the display will return to its normal condition.
6. When you are finished reviewing the macro’s contents, press the Set Button [triangle 15] to return the remote to normal operation. Resetting the Remote Depending on the way in which the remote has been programmed, there may be a situation where you wish to totally erase all changes that have been made to the remote and return it to the factory defaults.
Figure 155 • The programming or configuration process may also be stopped at any time by pressing the REM MENU Button [triangle 33]. The message shown in Figure 155 will appear, the data entered in the current process will be lost and the remote will return to normal operation. Any process that was underway when the button will be pressed must be restarted.
POWER ON Keypad 1. Press the Power Button [hexagon 3]. Remote 1. Press the ON Button [triangle 2]. 2. Press any Input Selector Button [triangle 4]. POWER OFF Keypad 1. Press the Power Button [hexagon 3]. a) To turn off only the local zone, after pressing the Power Button [hexagon 3] do nothing or press THIS KEYPAD. [hexagon 6] b) To turn off the Remote Zones in the same Entertainment Group, press ENT GROUP OFF. [hexagon 7] c) To turn off all Remote Zones, press ALL KEYPADS OFF.
g) Press ◄ PRESET ► [hexagons 8, 18] to select from up to 30 AM or FM preset stations as configured in the AVR21EN. Press ◄ [hexagon 8] to select the previous preset. Press ► [hexagon 18] to select the next preset. h) Press BACK [hexagon 12] to return to ENTERTAINMENT. i) Press MENU [hexagon 11] to return to MAIN MENU. Remote a) Press RADIO 1 or 2 [triangle 4]. b) Press AM/FM [triangle 34] to select band. c) Press TUNE◄◄ [triangle 18] or TUNE ►► [triangle 37] to manually select station frequency.
scan speeds will vary by device and brand. To escape scan, press ■ (STOP) [triangle 19] or ► (PLAY) [triangle 36]. DISC 3 (iPod) Keypad a) Press DISC 3. [hexagon 3] If the iPod is not playing the iPod Main Menu will appear on the Keypad Information Display [hexagon 13]. If it is playing audio program the NOW PLAYING SCREEN will appear. b) In the iPod MAIN MENU, press Arrow Up/Down [hexagons 6,7] to select Category. Options: Playlists, Artists, Albums, Genres, Songs, Composeres, Audiobooks and Video.
b) c) d) e) Press ► [triangle 36] to play video or resume play if video is paused or in scan mode. Press II [triangle 19] to pause video. Press ■ [triangle 19] to stop video. Press I◄◄ [triangle 16] or ►►I [triangle 39] to skip chapters or tracks. Press I◄◄ [triangle 16] once to return to the beginning of the current chapter/track. Press I◄◄ [triangle 16] twice quickly to return to the previous chapter/track. Press ►►I [triangle 39] to advance to the beginning of the next chapter/track.
h) To record video, press the Record Button (red circle) [triangle 19]. CABLE/SAT Keypad a) Press CBL/SAT [hexagon 17] b) Press ▲ CH [hexagon 6] to select next channel c) Press ▼ CH [hexagon 7] to select previous channel d) Press MENU [hexagon 21] to open menu e) Press SELECT [hexagon 20] to enter a Menu option f) Press UP/DOWN/LEFT/RIGHT [hexagons 9, 10, 17, 18] to navigate menu g) Press BACK [hexagon 12] to return to ENTERTAINMENT. h) Press MENU [hexagon 11] to return to MAIN MENU.
c) When Group has been selected, press and hold TALK [hexagon 6]. Speak into the keypad microphone [hexagon 2]. The Group selected for paging will receive announcement. Page Keypad a) Press PAGE KEYPAD [hexagon 8] to page an individual zone. b) Press KEYPAD NAME [hexagons 6, 7, 8, 9] for zone to be paged. For additional Keypads, Press > [hexagon 16]. Press < [hexagon 10] to return to previous page. c) When Keypad has been selected, press and hold TALK [hexagon 6].
b) Press M [hexagon 21] to set the MINUTE the zone is to turn ON within the hour selected. c) Press OFF [hexagon 7] to schedule the Wake up day(s). OPTIONS: Daily, Weekdays, Weekend, Custom, Off and Today. d) To configure Custom: I. Press SET. [hexagon 20] II. Press the days of the week to deselect (no black box) the days wake up is not to occur. [hexagons 6, 7, 8, 9, 18, 20, 21] III. Press BACK [hexagon 12]. e) Press RADIO 1 [hexagon 8] to select the source the zone is to Wake Up to.
Open a) Press OPEN [hexagon 21] to open the selected door. NOTE: The message DOOR OPENED will appear on the KP21 Information Display [hexagon 13] for the amount of time the door relay is active. If the Door Open function has been disabled for this door in this zone, the message: FEATURE DISABLED Check Settings will appear on the keypad Information Display [hexagon 13]. 4. Press BACK [hexagon 12] to select ANOTHER DOOR. 5. Press MENU [hexagon 11] to return to MAIN MENU. Remote 1.
SPEAKER EQ. Speaker EQ allows contouring of zone EQ by optimizing system settings for the specific models of popular speakers listed. If the speakers used do not appear in the list, select NOT LISTED. a) Press SPEAKER EQ [hexagon 6] b) Press the button next to the model of speakers connected to this keypad. [hexagons 6, 7, 8, 9] c) Press NOT LISTED [hexagon 6] if the specific model is not on the list. d) Press > [hexagon 16] to advance to the next page of speaker options.
b) Select the source to be selected when the zone is turned on with the keypad or remote.[hexagons 6, 7, 8, 20, 21] c) Press BACK [hexagon 12] to return to POWER ON MODE SETTINGS. This screen provides information regarding keypad firmware/software versions. There are no configurable settings in this screen. [hexagon 7] RESET SETTINGS. CAUTION: Pressing this button will reset this keypad’s settings to factory defaults. Any programming for timers or preferences will be erased.
TROUBLESHOOTING MULTIROOM TROUBLESHOOTING GUIDE SYMPTOM CAUSE POWER AVR21EN does not • No AC Power power up SOLUTION • Make certain that the AC power cord is plugged into a live outlet • Check to see whether the outlet is switchcontrolled WPS21 does not power up • No AC power • Make certain that the AC power cord is plugged into a live outlet • Check to see whether the outlet is switchcontrolled AVH21 does not power up Keypads do not power up CONTROL Keypad does not control AVR21EN • No AC power • Ch
AVH21 Hubs. (Audio is distributed via CAT5Ee between Hubs.) VIDEO No video from source • Source connection • Confirm source is connected to proper input on AVR21EN.
MULTIROOM SPECIFICATIONS AVH21 Audio Video Hub Dimensions: Video Inputs: Power Requirement: 13 3/8” W x 6 1/2” D x 3 1/2” H 6 F-type Composite Source; 7 F-type Composite Camera 6 F-type Composite Source Bypass, 7 F-type Composite Camera Bypass, 6 F-type Composite Zone Out 2 switchable 12/24 Volt Latching Triggers, 2 Dry Contact Latching Triggers 1 IEEE 1394, RJ45 Jack 7 RJ45 Jacks, 1 Expansion/Aux Keypad RJ45 Jack 24VDC (from WPS21) WPS21 Power Supply Hub Dimensions: Keypad Power Terminals: AVH21 Hub Pow
