User's Manual

ATM100
Version 1.0 page 5 of 14
Recommended operating Range
PARAMETER MIN TYP MAX UNIT
VDD, +5V Supply pin voltage 4.5 5.0 5.5 V
Ambient Temperature (TA) 0 60 ºC
Electrical Characteristics – DC
PARAMETER CONDITION MIN TYP MAX UNIT
TX Module Configuration Linked 35 mA
TX Module Configuration Searching 22 mA
TX Module Configuration Continuous TX 63 mA
RX Module Configuration Linked 35 mA
Electrical Characteristics – RF TX/RX
Operating Conditions: VDD = 4.5 to 5.5V, TA = 0°C to +60 °C, RF Freq = 2403.35-2477.35MHz, measured at RF
test connector. Typical specifications at TA = 25°C, VDD = 5.0V
PARAMETER CONDITIONS MIN TYP MAX UNIT
RF Channel Frequency Range 2403.35 2477.35 MHz
TX Output power 2.5 dBm
RX Sensitivity -88.7 dBm
Range (NLOS) 15 m
Range (LOS) 50 m
Notes;
1) Sensitivity is defined as the onset of 0.2% BLER Clock Error Rate.
