the orange wire with key switch ignition position wire but the disadvantage is that the LCD receiver sounds alert when the vehicle door is opened while the system enters into arm mode.
5.Blue wire: When this wire has negative input, the receiver’s LCD will show up
“trunk open” icon. Connect this wire with switch trigger wire.
l Choice of Mode # 2 on the control module:
Orange wire and blue are used to operate the main system “ON “ and “OFF”
The door lock/unlock system is used to operate main system to turn “ON” and “OFF” .Connect the 4
th
orange wire and the 5
th
blue wires with the 2 wires from the central lock. The main
system is turned “ON” and “OFF” when remote door lock/unlock is activated. While installing ; if the lock/unlock does not conform with the lock/unlock icons on receiver’s LCD, interchange the
orange and blue wire connection. For this mode, connect the trunk and hood pin wires together.
6.Purple wire: If this wire gets positive input , the receiver’s LCD shows “door open” icon. If the door switch pin is positive trigger, connect this with the door switch wire. [ But if the door switch
pin is negative trigger, leave the purple wire unconnected.]
7.Brown wire
For mode # 1: When this wire gets negative input, the receiver’s LCD shows up “trunk open” icon. Connect this with the hood pin trigger wire.
For mode # 2: When this wire gets negative input, the receiver’s LCD shows up both “ trunk open” and “ hood open” icons. Connect this with both the trunk and hood pin trigger wires.
8.Green wire: When this wire gets negative input , the receiver’s LCD shows up “door open” icon. For car whose door pin trigger wire is negative, connect this with door pin wire .[ If the door pin
trigger is positive, leave the green wire unconnected. ]
9. Void pin
10. Blue /white wire: If the mode # 2 is chosen, [ In case the door is opened with a key instead of remote control door opening , the main system might misjudge this as authorized “door open” and
disarm ] .To correct mis-adjustment problem ,locate the positive triggering wire of warning lights while remote door lock/unlock is activated (for example: parking light flash) and connect with
blue/white wire.
4 PIN HARNESS WIRE
1. RED WIRE: This is positive output of the main system and used to supply 12 volt current for shock sensor.
2. BLACK WIRE: This is the negative output of the main system and is used for ground connection with the shock sensor.
3. BLUE WIRE: While the system is in arm mode; if this wire gets negative input, the receiver’s LCD shows up light impact icon.
4. WHITE WIRE: While the system is in arm mode; if this wire gets negative input, the receiver’s LCD shows up heavy impact icon.
5 PIN HARNESS WIRE
Connect the wires of RF transmitter modules with the main control modules. Cut off connection between the 4
th
and 5
th
wire [ originally is connected by the factory ] to extend the transmission range
by increasing output power.
Choice of mode # 1 or # 2 of the main control module
There is a black wire loop sticking out of the control case. Keep this loop intact for choice of mode # 1 . Cut this loop if mode # 2 is chosen.
