Specifications
72 975-0004-01-02 Rev D
Environmental Specifications
The following lists the environmental specifications for the
C-Series controllers Models C35, C40, and C60.
Table A-3
Environmental Specifications
Model C35 C40 C60
Enclosure Type Indoor, ventilated, powder-coated steel with 3/4" and 1" knockouts.
Operating
Temperature Range
32 to 104 °F (0 to +40 °C)
Specifications at 25°C
Non-operating
Temperature
-67 to 284 °F (-55 to +75 °C)
Specifications at 25°C
Altitude Limit
(operating)
15,000 feet (5,000 meters)
Altitude Limit
(non-operating)
50,000 feet (16,000meters)
Dimensions
(H x W x D)
8" x 5" x 2.5"
(20.3 cm x 12.7 cm x 6.35 cm)
10" x 5" x 2.5"
(25.4 cm x 1.7 cm x 6.35 cm)
Mounting Vertical Wall Mount
Weight (Controller
only)
2.5 lbs (1.2 kg) 3.0 lbs (1.4 kg) 3.0 lbs (1.4 kg)
Weight (Shipping) 3.0 lbs (1.4 kg) 3.5 lbs (1.6 g) 3.5 lbs (1.6 kg)
*Specifications at 25°C
Specifications subject to change without notice
