Features and Options Specifications
The following lists the features and options specifications for
the C-Series controllers Models C35, C40, and C60.
Load Control Settings:
System Voltage:
Low Voltage
Reconnect
Low Voltage
Disconnect
12 Volt System:
LVR 12.0 to 14.0 Vdc
LVD 10.5 to 12.5 Vdc
24 Volt System:
LVR 24.0 to 28.0 Vdc
LVD 21.0 to 25.0 Vdc
48 Volt System:
LVR 48.0 to 56.0 Vdc
LVD 42.0 to 50.0 Vdc
Table A-2 Features and Options Specifications
Model C35 C40 C60
Standard Features
Status Indicator Multi color LED indicates the operating/battery voltage status.
Low Voltage Disconnect
Load Control Mode
User selectable manual or automatic reconnection - includes warning
flash before disconnect and 6 minutes “grace” period.
Equalization Charge
Charge Control Mode
User selectable manual or automatic equalization (every 30 days).
Short Circuit Protection Fully electronically protected with auto-reset.
Adjustable Control
Setpoints (test points
provided for high
accuracy
Two user-adjustable, voltage setpoints for control of loads or charging
sources (settings retained if battery is disconnected.)
Options
LCD Meter Panel
(CM, CM/R-50,
CM/R-100)
Back-lit, 32-character, alpha-numeric liquid crystal display panel for
remote (CM/R) or front mounting (CM) on the C-Series controller.
External Battery
Temperature Sensor
(BTS/15, BTS/35)
Provides automatic adjustment of the charge control set point to the
battery temperature (may be extended)
Table A-1 Electrical Specifications
Model C35 C40 C60
