VACUUM
86037780 EXTRACTOR 02/15/08
5
-
1
8
REF
PART
NO.
PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86173000 70914 3
SCR, KA40x20, PT OHS, WN1412,
PLTD
2A 86225480 53272 1 VAC MOTOR, 120V 5.7 3ST W/TUBE 115V ONLY
2B 86308980 - 1 VAC MOTOR ASM, 230V MINIPRO 230V ONLY
3 86173220 70954 4 SCR, M6X12 PHCS, 12.5MM HD, SS
4 86217420 270703 1 COVER, VAC MOTOR
5 86217370 270140 1 COVER, LOWER BACK
6 86006770 70323 1 SCR, 10-32 X 1/4 PHTR PLTD
7 86010640 87016 1 WASHER, #10 LOCK EXT STAR
8 86291680 - 1 GASKET, VAC MOTOR
