02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 41 Licensee Winchester Model 9410 Lever Action Shotgun Owner’s Manual — Top-Tang Safety Version
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 2 Important instructions for Winchester Model 9410 Lever Action .410 Shotgun With Top-Tang Safety Customer Service Department (United States) U. S. Repeating Arms Company, Inc. 275 Winchester Avenue Morgan, Utah 84050-9333 Phone: 1-800-945-5237 Winchester trademarks licensed from Olin Corporation. If you have any questions or comments regarding your new firearm, please feel free to write or call us.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Licensee Page 3 Contents Page Gun Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . .5 General Description . . . . . . . . . . . . . . . . . . . . . . . . .7 Terminology and Descriptions . . . . . . . . . . . . . . . . .8 Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Ammunition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 General Features . . . . . . . . . . . . . . . . . . . . . . . . . . .
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 4 THANK YOU We sincerely hope that you are pleased with your new Winchester 9410 shotgun. We at U.S. Repeating Arms Company thank you for the privilege of providing this shotgun to you. We are especially proud of the many years of enjoyment it is certain to provide for you and your family. The Model 9410 is another shotgun in an over 130 year-old tradition of producing quality firearms for the world’s sportsmen.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 5 2. Do not rely on the safety to prevent accidental discharge. Many safeties merely block the trigger and prevent firing by pulling the trigger. The safety may not prevent an accidental discharge due to dropping, jarring, or bumping a gun. GUN SAFETY WARNINGS IT IS ESSENTIAL THAT THESE OPERATING INSTRUCTIONS BE THOROUGHLY STUDIED BEFORE USING THIS FIREARM TO ASSURE PROPER AND SAFE GUN HANDLING.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 6 14. Never alter any parts of your gun. Any alterations or adjustments that may become necessary to the operating mechanism should be performed by a qualified gunsmith. 8. Keep barrel, chamber and action free of rust. Rust in the barrel and chamber can cause excessive pressures resulting in serious injury. A rusted, pitted or eroded barrel should be replaced. 15. Hunting from elevated surfaces such as tree stands is dangerous.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 7 FOR MODELS WITH THE RECEIVER POSITIONED CROSS BOLT MANUAL HAMMER STOP/SAFETY (FIGURE 3), PLEASE REQUEST A COPY OF THAT MANUAL BY CALLING 1-800-782-4440. GENERAL DESCRIPTION Congratulations on your purchase of a Winchester Model 9410 shotgun — certainly one of the most unique and fun-to-shoot guns ever. The original Winchester Model 94 design is famous for fast handling and natural pointability. No wonder it lends itself so well to a chambering in .
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Rebounding hammer Page 8 FIGURE 1A Rear sight Ejection port Barrel bands Front sight Manual hammer stop/safety Loading port Trigger guard Forearm Muzzle Magazine tube Trigger Finger lever Buttstock Butt plate focussing on the hammer and lever mechanisms (Figures 1B and 1C). You must be familiar with these part names in order to follow instructions contained in this book. Figure 1D covers the general features and benefits of the Model 9410 design.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 9 FIGURE 1B FIGURE 1C Manual hammer stop/safety Rebounding hammer Rebounding hammer Trigger stop Trigger Manual hammer stop/safety Trigger guard Finger lever Pushed forward: “off safe” Pushed to rear: “on safe” AMMUNITION Your Winchester Model 9410 is designed to shoot modern factory shotgun shells only. It is chambered in .410 bore with a 21⁄2" chamber length.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 10 MODEL 9410 GENERAL FEATURES Model 9410 Traditional model shown, other models differ slightly. All models are drilled and tapped for scope mounts. With a scope and the proper rifled slug your Model 9410 can be effective for varmints and game — with better results at extended ranges. The top-tang safety location preserves the classic look of the original Model 94 lever action rifles. The stock is profiled for fast handling and classic good looks.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 11 FIGURE 1D The ultra-strong breech block design has stood the test of time. The handling characteristics of the Model 9410 make it ideal for hunting small game in heavy brush or for use on varmints where there may be very little time to get off a shot at fast moving pests. Every Model 9410 comes with open sights. Most will feature a traditional drift-windage and elevation adjustable rear sight and ramp style front sight.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 12 Use only star crimped or roll crimped shells. Because the Model 9410 uses a tubular magazine, never use shells with protruding, pointed or conical point slugs. Never use a shell which has a slug protruding beyond the crimp. Failure to follow these instructions may result in injury to yourself or others, or cause damage to your gun. • Never attempt to load 3" shells. • Barrel has a smooth bore with no rifling.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 13 Incorrectly reloaded ammunition can cause serious personal injury and damage to the firearm due to excessive pressure. Reload only after proper instruction and in strict compliance with instructions and data contained in current reloading manuals. Lightly oil the action at these points FIGURE 2 INITIAL CLEANING Some metal parts of your new Model 9410 have been coated at the factory with a rust preventative compound.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 14 When the safety has been placed in the “on” position, it serves the function of blocking the hammer from striking the firing pin. Even if the safety is on, it does not prevent the hammer from falling to the rebound position when the trigger is pulled. When the trigger is pulled — with the safety on — the hammer drops, going immediately to the rebound position without impacting the firing pin. is prevented from moving forward and striking the firing pin.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 15 position when the trigger is pulled. When the trigger is pulled — with the safety on — the hammer drops, going immediately to the rebound position without impacting the firing pin. The “on” position is the recommended position of the hammer for all times except when firing is imminent.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 16 imminent, it is important to lower the hammer immediately to the rebound position from the cocked position. To do this: Firmly hold the hammer back FIGURE 7A 1. Make sure the barrel is pointed in a safe direction and that the safety (manual hammer stop/safety) is in the “on” position (Figure 5A). 2. Get a stable grip on your shotgun with your hand in shooting position.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 17 manually and visually to avoid any chance of accidental discharge. Always keep the manual hammer stop/safety in the “on” position unless you are actually firing the shotgun. It is a good idea to keep the action open (with the finger lever down) at all times other than when you are in the field and shooting is imminent.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 18 hammer will fall and strike the firing pin. If a cartridge is in the chamber, the firing pin will strike the primer and fire the cartridge. When the hammer is in the cocked position, the hammer stop/safety should be in the “on” position (with the “S” showing) unless firing is imminent.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 19 5. When the proper eye relief is found, tighten the cap screws in a rotating, crossing pattern. Do not over tighten so as to strip the screws or damage the scope tube. in some situations you may want the advantage of a scope or dot type sight. Scope mounts are available separately. General instructions for installing scope mounts are outlined below. Most systems will be similar to the ones explained here.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 20 part-to-part fit for many years to come and is the sign of a finely crafted firearm. FIGURE 10 LOADING PROCEDURES USE THE CORRECT AMMUNITION AS INDICATED BY THE INSCRIPTION ON THE BARREL. AS EXPLAINED PREVIOUSLY, BEFORE LOADING YOUR SHOTGUN MAKE SURE ALL GREASE AND OIL HAS BEEN REMOVED FROM THE BARREL AND CHAMBER, AND THERE ARE NO OBSTRUCTIONS IN THE BARREL OR ACTION AREAS.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 21 FIGURE 12 Cover closed Insert the shell through the loading port FIGURE 13 Push the last shell fully in, allowing the cover to close rebound position, press the spring cover inward with the crimp end of the first shell until the entire shell has entered the loading port (Figure 12). Be sure to check the shell to make sure it is a 21⁄2" shell and not a 3" shell. If it is a 3" shell do not use it or try to chamber it in your Model 9410.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 22 directly into the chamber with the magazine already loaded it may be difficult or impossible to close the action. You may need to remove the shell from the chamber manually to allow the shell on the carrier to move into position for chambering. IT REARWARD WITH YOUR THUMB, EXPOSING THE “S” IN FRONT OF THE SAFETY LEVER. KEEP YOUR FINGER AWAY FROM THE TRIGGER WHEN CYCLING THE ACTION.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 23 end of the shell cannot clear the magazine tube. To remove the shell from the action follow these steps: FIGURE 14 Carefully inspect the chamber and feed/magazine mechanisms for any shells 1. Place the manual hammer stop/safety in the “on” position and the hammer in the rebound position. 2. Close the action, returning the shell back into the magazine tube. You may have to work the lever a bit to move the crimp end of the shell past the cartridge.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 24 IN THE CASE OF A MISFIRE FIGURE 15 Only rarely will modern factory ammunition experience a misfire. If this ever happens to you when shooting your Model 9410, please follow these instructions carefully. CAUTION: IN CASE OF MISFIRE, KEEP THE BARREL POINTED IN A SAFE DIRECTION, PLACE THE MANUAL HAMMER STOP/SAFETY IN THE “ON” POSITION AND CAREFULLY OPEN ACTION WHILE AVOIDING DIRECT EXPOSURE TO THE BREECH BY YOURSELF AND OTHERS.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 25 With a loaded shell in the chamber, the manual hammer stop/safety in the “on” position, the hammer in the safety (rebound) position and your finger off the trigger: FIGURE 17 Cocking the hammer to fire 1. Firmly position your thumb on the hammer and draw the hammer back to the full-cock position (Figure 17). 2. Place the manual hammer stop/safety in the “off” position (Figure 18) by pushing it all the way forward.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 26 FIGURE 19 Move the elevator forward to shoot lower, rearward to shoot higher Push the hammer stop/safety from front to back to the “on safe” position FIGURE 20 Sight elevator Lift up on the blade holder HAMMER TO THE REBOUND POSITION. 3. WHEN THROUGH FIRING ALWAYS IMMEDIATELY PLACE THE TOP-TANG SAFETY IN THE “ON” POSITION (FIGURE 19), AND THE HAMMER IN THE SAFETY (REBOUND) POSITION (FIGURE 6).
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 27 UP OR DOWN ELEVATION ADJUSTMENTS — FIGURE 21 Adjusting elevation on your Model 9410 requires you to lift up the rear notch blade holder on your shotgun’s rear sight with your fingers and move the notched elevator either forward or backward (Figure 20). To raise point of impact, use your fingers to lift up on the blade and slide the elevator rearward. Adjusting the sight to make your gun shoot lower is just the opposite — move the elevator forward.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 28 SIGHT MAINTENANCE — FIGURE 22 Correct sight picture — Slugs Occasionally check your sights to make sure they have not been jarred or vibrated out of adjustment. This is especially important after extensive shooting or after hunting under rugged conditions. If so equipped, check the two screws holding the rear sight blade in place on the blade mount and carefully tighten if necessary. Check the screw holding the front sight base to the barrel.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 29 STANDARD INVECTOR™ THREADED CHOKE TUBE SYSTEM TUBES MARKED STANDARD INVECTOR IN YOUR MODEL 9410 SHOTGUN. Some Model 9410s are fitted with the interchangeable Standard Invector™ choke tube system. If your shotgun has the words “Standard Invector” inscribed on the side of the barrel, then you have the system.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 30 CHECKING, FOLLOW THE SAFETY GUIDELINES OUTLINED ABOVE. 3. Use the Standard Invector wrench to loosen the tube, turning it counterclockwise. Finger twist the tube the rest of the way out of the barrel. Replacement and additional tubes and wrenches are available from your Winchester firearms dealer. TUBE INSTALLATION — STANDARD INVECTOR CHOKE IDENTIFICATION — 1. Place the safety in the “on safe” position and fully unload your Model 9410.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 31 off and lodge in the threads, making installation and removal difficult. FIGURE 24 1 3 4 5 Full Modified Improved Cyl. Skeet 2. Regularly remove your gun’s tube in order to clean and oil the threads inside the barrel, as well as on the choke tube itself. This will protect the threads from being damaged and also prevent a dirt build up that would cause the choke tube to become difficult to remove from the barrel.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 32 FIGURE 28 FIGURE 26 Insert the threaded end into the threaded hole and tighten Three shot adapter inside magazine preferred and fully tighten the hammer extension in the tapped hole in the hammer (Figure 26). (Right-handed shooters usually prefer mounting the extension to the right side.) FIGURE 27 WARNING: HAMMER EXTENSIONS CAN LOOSEN WITH USE. OCCASIONALLY CHECK TO MAKE SURE YOUR HAMMER EXTENSION IS STILL ON TIGHTLY.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 33 2. Loosen and remove the magazine end cap retaining screw located on the underside of the forward end of the magazine tube (Figure 27). MAGAZINE PLUG The 9410 is delivered with a three-shot adapter plug included in the box. This plug limits magazine capacity to two shells in compliance with federal migratory bird (doves are migratory birds) regulations and regulations in some states.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 34 FIGURE 29 FIGURE 30 Tilt magazine tube away from barrel while keeping pressure on end cap Turn sling swivel stud counterclockwise to loosen 6. Replace the magazine end cap, pushing the spring back down into the magazine tube. remove the magazine end cap from the magazine by tilting the magazine tube away from the barrel enough to clear the sling post mounting stud on the barrel (Figure 30). Remember, magazine is under spring load. 7.
02-224-WFA_9410_OM_revis Flat spot of end cap faces away from barrel 7/16/03 2:52 PM Page 35 2. Remove the two screws on the front of forearm cap using a standard screwdriver. FIGURE 31 3. Pass a small screwdriver through the hole in the sling post found on the end of the magazine tube. Turn the post counterclockwise to loosen the post (Figure 29). 4. Slide forearm cap forward on magazine tube.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 36 MAGAZINE ARE UNLOADED. ALWAYS WEAR PROTECTIVE SAFETY GLASSES DURING ALL CLEANING PROCEDURES. KEEP AMMUNITION AWAY FROM THE CLEANING AREA. DO NOT TEST THE FUNCTION OF YOUR FIREARM WITH LIVE AMMUNITION. 10. Return forearm cap to original location and secure forearm cap with screws. CLEANING AND MAINTENANCE SUGGESTIONS The Model 9410 will function better and more reliably over a longer period of time if it is properly maintained and kept clean.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 37 7. Wipe all wood surfaces. breaking off, the brush should be pushed completely through the bore before being withdrawn. If cast lead slugs are used a lead solvent may be used as well to fully clean the bore. Follow the instructions on all solvents and cleaners. 8. When transporting only, store your gun in a quality protective case to prevent scratches and dents. Store in a dry place to prevent corrosion. Store away from children.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 38 This is a specialized, finely fitted mechanism. You may permanently mar it by attempting to disassemble the inner mechanism assemblies. If further disassembly for service or cleaning is required, take your gun to a U. S. Repeating Arms Company Authorized Repair Center or a competent gunsmith as explained under “Service or Repair.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 39 WINCHESTERGUNS.COM U.S. Repeating Arms Company offers an information resource for you on the world wide web. • List of authorized repair centers. • Customer service information. • Answers to many technical and historical questions. • Links to helpful sites. Go to: www.winchesterguns.
You Are Responsible For Firearms Safety. As a gun owner, you accept a set of demanding responsibilities. How seriously you take these responsibilities can mean the difference between life and death. Failure to follow any of these instructions can cause extensive damage to your gun and/or possible serious injury or death to yourself and others. There is no excuse for careless or abusive handling of any firearm. At all times handle any firearm with intense respect for its power and potential danger.
7. BEWARE OF BARREL OBSTRUCTION. Do this for the safety of both your gun and yourself. Mud, snow, and an infinite variety of other objects may inadvertently lodge in a barrel bore. It takes only one small obstruction to cause dangerously increased pressures that can ruin (swell or rupture) the finest shotgun barrel. BEFORE CHECKING FOR A BARREL OBSTRUCTION, BE CERTAIN YOUR FIREARM IS FULLY UNLOADED. Make sure no live rounds are in the chamber.
12. USE SHELLS OF CORRECT LENGTH. The size of the chamber is inscribed, along with gauge and choke designations, on the side of the barrel. Do not use 31/2" shotgun shells in a shotgun or barrel with a 2 3/4" chamber or 3" chamber. Do not use 3" shells in a shotgun chambered for a 2 3/4" shells. Doing so can result in a build-up of dangerously high pressures that may damage your gun and possibly cause serious injury to yourself or others. 13.
22. SUPERVISE AND TEACH FIREARMS SAFETY TO ALL MEMBERS OF YOUR FAMILY -ESPECIALLY TO CHILDREN AND NONSHOOTERS. Closely supervise newcomers to the shooting sports. Encourage enrollment in hunting/shooting safety courses. 23. NEVER DRINK ALCOHOLIC BEVERAGES OR TAKE ANY TYPE OF DRUGS BEFORE OR DURING SHOOTING. Your vision and judgment could be dangerously impaired, making your gun handling unsafe to you and to others. 24. PERFORM PERIODIC MAINTENANCE -- AVOID UNAUTHORIZED SERVICING.
02-224-WFA_9410_OM_revis 7/16/03 2:52 PM Page 40 Licensee U.S. Repeating Arms Company, Inc. 275 Winchester Avenue Morgan, Utah, U. S. A. 84050-9333 www.winchesterguns.com Winchester trademarks licensed from Olin Corporation.
