10 Appendix C: Pin-allocation of the Data-
cables
10.1 WIMAN Datacable (10 x 2)
Pin Wire color (1. line) Pin Wire color (2. line)
1 White/Grey 14 White/Green
2 - 15 Brown/Green
3 White/Yellow 16 Pink/Brown
4 Yellow/Brown 17 White/Pink
5 White 18 Grey/Pink
6 Brown 19 Red/Blue
7 - 20 -
8 Grey/Brown 21 Black
9 Green 22 Purple
10 Yellow 23 -
11 Pink 24 Red
12 Grey 25 Blue
13
Table 7 WIMAN data cable (10 x 2), pin assortment
Attention:
Provide a correct grounding of the data cable screen.
Paired-wire Wire color Pin number Wire color Pin number
1 White 5 Brown 6
2 Green 9 Yellow 10
3 Grey 12 Pink 11
4 Blue 25 Red 24
5 Black 21 Purple 22
6 Grey/Pink 18 Red/Blue 19
7 White/Green 14 Brown/Green 15
8 White/Yellow 3 Yellow/Brown 4
9 White/Grey 1 Grey/Brown 8
10 White/Pink 17 Pink/Brown 16
Shield Shield
Table 8 WIMAN data cable (10 x 2) paired-wire assort-
ment
