INSTALLATION GUIDE & USER MANUAL Sound Plus™ Infrared Listening System Model WIR TX90, Two Channel System Model WIR SYS 90V, Two Channel System Model WIR SYS 90 PRO, Two Channel System Transmitter Model WIR TX90 Optional Receiver Models WIR RX22-4, WIR RX14-2, WIR RX18 Optional Charger Models CHG 518, CHG 3512 MAN 119E
SOUNDPLUS™ INFRARED LISTENING SYSTEM, Model WIR TX90, Two-Channel Listening System Model WIR SYS 90V, Two-Channel Listening System Model WIR SYS PRO, Two-Channel Listening System INSTALLATION GUIDE & USER MANUAL CONTENTS PAGE System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Installation Procedures Determining Coverage Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SYSTEM OVERVIEW The WIR TX90 two channel infrared transmitter combines infrared modulator and emitter technology into a single mountable enclosure - reducing operating cost and eliminating precious rack space. The WIR TX90 features an easy to use configuration preset for Music, Voice, or Hearing Assistance Applications. It operates on dual 2.3/2.8 or 3.3/3.8 MHz selectable frequencies - ideal for high quality audio programs such as music, theater and audio description.
u DETERMINE COVERAGE AREA Determine the coverage area needed for the seating area. When using the WIR TX90 transmitter with the RX22-4 receiver, in single channel mode, the WIR TX90 can achieve a coverage area of 28,000 ft2 (2,600 m2). In four channel mode, the WIR TX90 divides its power among the four signals to achieve a coverage area of 11,000 ft2 (1,022 m2). NOTE: The coverage area will vary depending on the sensitivity of the infrared receiver being used.
FIGURE 3: 3 DIMENSION FOOT PATTERN FIGURE 5: OVERLAPPING ILLUMINATION FIGURE 4: NOTE: WHEN POINTING THE EMITTER, BE SURE TO KEEP THE LONG DIMENSION HORIZONTAL.
FIGURE 7: WIR TX90 REAR VIEW Power Connection Plug in Power Supply 120 VAC (US): TFP 010 230 VAC (CE): TFP 027 Wall/Ceiling Mounting Bracket (BKT 024) Set of threaded holes for use with mounting bracket Baseband Out BNC Connector, 50 Ω 50 kHz-8 MHz Baseband u CONNECT POWER WARNING: POWERLINE VOLTAGE MUST NOT FALL BELOW 90V, 0R SYSTEM PERFORMANCE WILL BE GREATLY REDUCED! POWER CONNECTION FOR U.S.
u CONNECT AUDIO SOURCE Determine the length of the audio cable needed to connect to the sound system to the WIR TX90 transmitter. Install the supplied Phoenix connector on the end of the audio cable to be connected to the transmitter. See the back of the WIR TX90 for wiring instructions. FIGURE 9: AUDIO SOURCE CONNECTIONS The WIR TX90 will accept line level, balanced or unbalanced audio inputs.
u SELECT AUDIO PROCESSING APPLICATION PRESET The WIR TX90 offers three preset audio processing options for the most common applications: Music, Voice, and Hearing Assist. Use the “Music” setting when maximum dynamic range and audio quality are preferred. Use the “Voice” setting for simultaneous interpretation, audio description, or other applications with users that have primarily normal hearing.
USING THE OPTIONAL WIR TX9 SLAVE EMITTER FOR ADDITIONAL COVERAGE For larger facilities, additional emitter panels can be used to increase the overall coverage area. In these cases, we recommend using the WIR TX9 slave emitter in tandem with the WIR TX90. The WIR TX90 can drive multiple WIR TX9 emitters at one time. Each TX9 emitter will require its own power supply.
RECEIVER SAFETY INFORMATION HEARING SAFETY Williams Sound receivers are designed to amplify sounds to a high volume level which could potentially cause hearing damage if used improperly. To protect your hearing and the hearing of others: CAUTION! 1. 2. 3. 4. BATTERY SAFETY Make sure the volume is turned down before putting on the earphone or headphone before adjusting the volume to a comfortable level. Set the volume level at the minimum setting that you need to hear.
OPTIONAL INFRARED RECEIVERS FIGURE 13: FOUR CHANNEL RECEIVER, MODEL WIR RX22-4 Channel 1 2 3 4 Frequency 2.3 MHz 2.8 MHz 3.3 MHz 3.
OPTIONAL CHARGERS FIGURE 16: MULTIPLE BATTERY CHARGER, MODEL CHG 518 CHG 518 Top CHG 518 Back FIGURE 17: MULTIPLE BATTERY CHARGER, MODEL CHG 3512 CHG WARNING: DO NOT ATTEMPT TO RECHARGE DISPOSABLE BATTER WARNING: IES! DO NOT CHG ATTEMPT TO RECHA RGE CHG Williams Sou nd DISPOSABLE BATTE RIES! CHG Williams Soun d CHG CHG CHG CHG CHG WARNING: DO NOT ATTEM PT TO RECHARGE DISPOSABLE BATTE CHG CHG RIES! WARNING: DO NOT ATTE MPT TO RECH ARGE DISPOSABL E BATTERIES ! CHG CHG 3512 Top 12
TROUBLE SHOOTING THE WIR TX90 “POWER ON” INDICATOR IS NOT LIT. þ Make sure the transformer is plugged into the transmitter and any remote power switch is on. þ þ Make sure the electrical outlet is on. Make sure the 24 VAC power supply is working. THE WIR TX90’S CHANNEL A OR B “ON” INDICATOR IS NOT LIT. þ Make sure the desired audio channel has been activated. See Selecting a Channel on page 7. þ Make sure the WIR TX90 is plugged in. þ Make sure the audio input is connected properly.
LIMITED WARRANTY Williams Sound products are engineered, designed, and manufactured under carefully controlled conditions to provide you with many years of reliable service. Williams Sound warrants the Sound Plus™ Infrared Listening System against defects in materials and workmanship for FIVE (5) years. During the first five years from the purchase date, we will promptly repair or replace the Sound Plus™ Infrared Listening System.
SOUNDPLUS™ INFRARED LISTENING SYSTEM SPECIFICATIONS MODEL WIR TX90 INFRARED TRANSMITTER, MODEL WIR TX90 Dimensions, Weight: Color: Power Supply: Power Cable: Modulation: Carrier Frequency: Emitter IR Power: Coverage Area: Signal-to-Noise Ratio: Frequency Response: Total Harmonic Distortion: Compression: Auto Carrier Shut-Off: Power Indicator: Audio Volume Level Controls: Audio Indicators: Carrier LEDs: Phones Output: Application Preset: Tone Control: Power Input: Audio Input Connector: Input Level: Baseb
