Specifications

SATA2.5TestAdapterUserManual


Page|32
©2010,2011WilderTechnologies,LLC
DocumentNo.910‐0011‐000Rev.B




Figure 17. Typical Differential NEXT, without connector (top) and with mated connectors (bottom),
adjacent differential pairs, both transmit and receive terminated at both ends
