SATA2.5‐TPA‐PCablePinout
TheSATA2.5‐TPA‐PcablesprovidefourSMAconnectors(onelaneofprimarydifferentialTX
andRX).Labelsclearlymarkeachcableorconnector.Thefollowingfigurereferstothepin‐
descriptiontablefortheplugconnector.



Figure 5. Cable Connectors (SATA2.5-TPA-P shown)

4SMAsfor
High‐Speed
Testing
ColorIDfor
DataLinePolarity
(SeeTable3)
ColorIDfor
DifferentialPair
(SeeTable3)
PlugConnector
(SeeTable3)
