Specifications

SATA2.5TestAdapterUserManual


Page|18
©2010,2011WilderTechnologies,LLC
DocumentNo.910‐0011‐000Rev.B
MechanicalandEnvironmentalSpecifications
NOTE:Allspecificationsinthismanualaresubjecttochange.
Table 1. General Specifications
ITEM DESCRIPTION
UsageEnvironment Controlledindoorenvironment
PlugTestAdapterLength(w/standardcables) 171.7mm+/‐2mm(6.76inches+/‐.08inches)(Characteristic)
ReceptacleTestAdapterLength(w/std.cables) 173.0mm+/‐2mm(6.81inches+/‐.08inches)(Characteristic)
OperatingTemperature 0°Cto+55°C(32°Fto+131°F)(Characteristic)
StorageTemperature‐40°Cto+70°C(‐40°Fto+158°F)(Characteristic)

SATA2.5‐TPA‐RCablePinout
TheSATA2.5‐TPA‐RcablesprovidefourSMAconnectors(onelaneofprimarydifferentialTX
andRX).Labelsclearlymarkeachcableorconnector.Thefollowingfigurereferstothepin‐
descriptiontableforthereceptacleconnector.


Figure 4. Cable Connectors (SATA2.5-TPA-R shown)
 
4SMAsfor
High‐Speed
Testing
ColorIDfor
DifferentialPair
(SeeTable2)
ColorIDfor
DataLinePolarity
(SeeTable2)
Receptacle
Connector
(SeeTable2)
