Product Specifications

For Global Market
275W~290W
5BB-Monocrystalline PV Module
CHSM6610M Series
CHSM6610M/HV Series
CHSM6610M max system voltage 1000V standard
CHSM6610M/HV max system voltage 1500V standard
10-year
Warranty for Materials and Processing
25-year
Warranty for Extra Linear Power Output
(
1
st
year ≤ 3%, 2
nd
~25
th
years ≤ 0.7% / year
)
97%
KEY FEATURES
+
5W
Anti
PID
6000
3600
IEC TS 62941
First solar company which passed the TUV
Nord IEC/TS 62941 certication audit.
OUTPUT POSITIVE TOLERANCE
INNOVATIONAL 5-BUSBAR CELLS
PID RESISTANCE
EXCELLENT MECHANICAL LOAD CAPABILITY
HIGHER RELIABILITY AND DURABILITY
PASSED HAIL TEST
LOWER TEMPERATURE COEFFICIENT
Guaranteed 0~+5W positive tolerance ensures power output reliability.
Reduces the cell series resistance and internal stress, decreases the risk
of mirco-crack and improves the module output.
Excellent PID resistance at 96 hours (@85
℃
/85%) test, and also can be
improved to meet higher standards for the particularly harsh environment.
Certied to withstand: snow load (6000 Pa) and wind load (3600 Pa).
E󰀨ectively deals with harsh environments,such as sand, salt mist and
ammonia resistance.
Certied to hail resistence: ice ball size (d=45mm) and ice ball velocity
(v=30.7m/s).
Improved temperature coe󰀩cient decreases power loss in the high
temperature application.
COMPREHENSIVE CERTIFICATES
Tier 1
No.1
Bloomberg
PHOTON
DNV GL
80.20%
Optional: Black frame designed for the certain projects
and applications (e.g. residential rooftop and so on)
AstroNova
TM
2018 TOP
Performance
Protable for Decades
3rd party
Reinsurance
