Flush Mount Cut Out Suggestion
304mm
(
12”
)
289mm
(
11.5”
)
Cut
57mm 2.2”
Cable Outlet
3cm free space around pad
for ventilation.
Antenna pad to control box
2.5m, 8.2 ft
Control box to
AC
1.8m, 6 ft
Flange:
307 x 322 mm
12.1x 12.7in
