User's Manual

23
Key ID “H” - Minimum Signal Adjustment (valid range: 0-8, increment 1)
Lowering this number will increase the label detection sensitivity of the
FastPad, but will also increase the risk of false deactivation. Vice versa,
raising it will decrease the sensitivity or detection range to adapt to
deactivation range.
While there are two antenna channels, FastPad has only one H value
adjustment, and it will apply to both of the antenna channels for minimum
signal adjustment.
Press [MIN]. The LEDs will display as shown as below
Input number for the parameter.
Press [CON] to accept the parameter.
Key ID “E” – Load Default Settings (default value: 0; valid range: 0-1)
Value Action
0 Initial state, no meaning
1 Load default settings
Input value 1 will load the default settings (refer to the Default Parameters
Table on page 10).
LAN
REMOTE CONTROL
0 H
