User's Manual

22
After confirmation, the panel will display a different signal or noise level from
the specific antenna channel.
Noise Condition Display Configuration Table
Value Function Description Detection Purpose
0
Shut down tag or noise window
display.
D1 Tag window display for channel 1. Detect tag by antenna CH1.
D2 Tag window display for channel 2. Detect tag by antenna CH2.
D3
Average noise window display for
channel 1.
Monitor long time average noise
received by antenna CH1.
D4
Average noise window display for
channel 2.
Monitor long time average noise
received by antenna CH2.
Note: D3/D4 indicate the average noise level and also the weighted Minimum
Signal Adjustment value. It gets the MAX value between average noise and
MIN value. Therefore, if MIN (H value) is increased to be bigger than the
average noise level, D3/D4 will indicate only H value instead of average noise
value.
LAN
REMOTE CONTROL
2 -
