User's Manual

20
When the correct password is verified, the LEDs will display as per the
following picture and wait for configuration type input.
Key ID “B” - Sync Adjustment (range: 0-99; increment: 1)
This adjustment sets the time from zero crossing point to the start point of
burst transmission. It is used for eliminating cross talk between different
systems. In most cases the default b-1 value will achieve system stability with
respect to other AM products.
Press [SYN] and the LEDs will display as shown below.
Input the number for the parameter.
Press [CON] to see the noise conditions.
Note: The adjustable range is 0-99 (0 – 3.366ms), with each increment
equaling 34µs. (34µs x 99 total increments = 3366µs = 3.366ms)
LAN
REMOTE CONTROL
-
LAN
REMOTE CONTROL
1 b
