User's Manual

16
IR REMOTE CONTROL KEYPAD DESCRIPTION
Control Keys Description & Default Parameters Table
Key ID Button Parameters Description
Default
Value
Valid
Range
Page
PSW Activates the Control Box IR Receiver NA NA 15
B SYN Sync Adjustment 3 0 to 99 16
H MIN
Minimum Signal Adjustment
(Sensitivity adjustment)
3 0 to 8 19
D NSE Noise Display (2 channels) NA 0 to 8 17-18
E DFT Return to Default Settings 0 0 to 1 19
F TX OFF Media Products Deactivation 0 0 to 1 19
L ARM RST Alarm Count Reset 0 0 to 1 20
P PC Password change 68 (*Note) 0 to 99 20
S SA Save Parameters to Flash ROM NA NA 20-21
CON Confirm Parameters Input NA NA
EX Exit NA NA
* NOTE: The default password (68) can be changed with the PC button. Thereafter the
system will use the new number as the default password. The new password will remain
saved even after power off. THIS IS A NON-RECOVERABLE ACTION. KEEP THE NEW
PASSWORD IN A SAFE LOCATION IN CASE YOU FORGET IT.
SA EX
MIN2
MIN1
RE
GN
SYN
NSE
A
RM
OFF
A
RM
RST
DFT
PC
TX
OFF
0
8
9
7
4
5
6
21
CON
PSW
3
