8-5

The Status Screens

8.5. The Current Metering Status Screen (VMR Only)

The Current Metering Status screen is used to display up-to-date readings for Amps,

Watts, Voltage and temperature for the VMR unit. To view the Current Metering Log

screen, access the VMR command mode and then proceed as follows:

Note: Current and Power Metering functions are not available on NPS units.

• TextInterface: Type /M and press [Enter].

• WebBrowserInterface: Place the cursor over the "Current Metering" link on the

left hand side of the screen. When the fly-out menu appears, click on the "Current

Metering Status" link.

The Current Metering Status screen lists the following parameters:

• CurrentA: The total current consumption, in Amps, for power circuit A.

• VoltageA: The total voltage for power circuit A.

• PowerA: The total power consumption, in Watts, for power circuit A.

• CurrentB: The total current consumption, in Amps, for power circuit B (if present.)

• VoltageB: The total voltage for power circuit B (if present.)

• PowerB: The total power consumption, in Watts, for power circuit B (if present.)

• Temperature: The rack temperature(s) currently detected by the VMR unit(s).

• TotalCurrent: The total current, in Amps, for both power circuits.

• TotalPower: The total power, in Watts, for both power circuits.

• OverTemperature: Lists the values for the Initial Threshold and Critical Threshold

for the Over Temperature Alarms. Note that when the Current Metering Status

Screen is viewed via the Web Browser Interface, Over Temperature Alarm settings

are not listed. To view Over Temperature Alarm settings via the Web Browser

Interface, please use the Current History Screen as described in Section 8.6. For

more information on the Over Temperature Alarms, please refer to Section 7.2.

• OverCurrent: Lists the values (as a percentage) for the Initial Threshold and

Critical Threshold for the Over Current Alarms. For more information on the Over

Current Alarms, please refer to Section 7.1.

• PowerFactor: The user-defined Power Factor value.

• PowerEfficiency: The user-defined Power Efficiency value.
