7-11

Alarm Configuration

• Address1,2,and3: These parameters are used to select which of the three email

addresses defined via the "Email Messages" menu (see Section 5.9.11) will receive

the email alarm notification messages generated by this alarm. The Address

parameters can be used to select one, or any combination of the addresses defined

via the Email Messages menu. (Default = All On.)

Note: If Email addresses have been previously specified, then the text under

the parameters will list the current, user defined email addresses.

• Subject: This parameter is used to define the text that will appear in the "Subject"

field for all email notification messages generated by this alarm. (Default = "Alarm:

Lost Voltage (Line In)")

7.5. The Ping-No-Answer Alarm

The Ping-No-Answer Alarm is intended to provide notification when one of the IP

addresses defined via the Ping-No-Answer Reboot feature (described in Section 6.1)

fails to respond to a Ping command. When one of the user-defined IP addresses fails

to answer a Ping command, the VMR/NPS can provide notification via Email, Syslog

Message or SNMP Trap.

Notes:

• In order for the Ping-No-Answer Alarm to work properly, your network and/or

firewall, as well as the device at the target IP address, must be configured to

allow ping commands.

• In order for this alarm to function, IP Addresses for the Ping-No-Answer

reboot feature must first be defined as described in Section 6.1.

• When a Ping-No-Answer condition is detected, the VMR/NPS can still reboot

the user-selected outlet(s) as described in Section 6.1, and can also send an

email, Syslog Message and/or SNMP trap as described in this section.

• In order for the VMR/NPS to provide Email alarm notification, communication

parameters must first be defined as described in Section 5.9.11.

• In order for the VMR/NPS to provide Syslog Message notification, Syslog

parameters must first be defined and Syslog Messages must be enabled as

described in Section 5.9.2 and Section 11.

• In order for the VMR/NPS to provide SNMP Trap notification when this alarm

is triggered, SNMP parameters must first be defined, and SNMP Traps must

be enabled as described in Section 5.9.7 and Section 12.

To configure the Ping-No-Answer Alarm, you must access the VMR/NPS command

mode using a password that permits Administrator Level commands. The Ping-No-

Answer alarm configuration menu offers the following parameters:

• TriggerEnable: Enables/Disables the trigger for this alarm. When Disabled, this

alarm will be suppressed. (Default = On.)

Note: To cancel an alarm without correcting the condition that caused the

alarm, simply toggle the Trigger Enable parameter to Off and then back On

again.
