Alarm Configuration

7.4. The Lost Voltage (Line In) Alarm

The Lost Voltage (Line In) Alarm can provide notification after the power supply to the

VMR/NPS unit has been interrupted.

Notes:

• The Lost Voltage (Line In) alarm is only available on VMR/NPS units that

include two input power lines.

• The Lost Voltage (Line In) alarm will provide notification when one of the

available power supplies is lost or disconnected. This alarm will not function

if all input power to the VMR/NPS unit is lost. To provide notification when

all input power is lost and restored, please use the Power Cycle Alarm as

described in Section 7.7.

• In order for the VMR/NPS to provide alarm notification via Email,

communication parameters must first be defined as described in

Section 5.9.11.

• In order for the VMR/NPS to provide alarm notification via Syslog Message,

Syslog parameters must first be defined and Syslog Messages must be

enabled as described in Section 5.9.2 and Section 11.

• In order for the VMR/NPS to provide alarm notification via SNMP Trap, SNMP

parameters must first be defined, and SNMP Traps must be enabled as

described in Section 5.9.7 and Section 12.

To configure the Lost Voltage (Line In) Alarm, you must access the VMR/NPS command

mode using a password that permits Administrator Level commands. The Lost Voltage

Alarm Configuration menu offers the following parameters:

• TriggerEnable: Enables/Disables the trigger for this alarm. When Disabled, this

alarm will be suppressed. (Default = On.)

Note: To cancel an alarm without correcting the condition that caused the

alarm, simply toggle the Trigger Enable parameter Off and then back On again.

• ResendDelay: Determines how long the VMR/NPS will wait to resend an email

message generated by this alarm, when the initial attempt to send the notification

was unsuccessful. (Default = 60 Minutes.)

• NotifyUponClear: When enabled, the VMR/NPS will send additional notification

when the situation that caused the alarm has been corrected. For example, when

Notify Upon Clear is enabled, the VMR/NPS will send initial notification when it

detects that one of it's power supplies has been lost or disconnected, and then

send a second notification when it determines that power has been restored.

(Default = On.)

• EmailMessage: Enables/Disables email notification for this alarm. (Default = On.)

Note: The Email Message parameter offers four different options: On, Off, On

(Copy to All Triggers) or Off (Copy to All Triggers). If either of the "Copy to All

Triggers" options is selected, then email notification for all other alarms will be

switched On or Off as indicated by this parameter. For example, If "Off (Copy

to All Triggers)" is selected, then Email notification will be disabled for all other

alarms too.
