7-9

Alarm Configuration

7.3. The Circuit Breaker Open Alarm

The Circuit Breaker Alarm is intended to provide notification in the event that one of the

VMR/NPS's circuit breakers is opened. When a circuit breaker is open, the VMR/NPS

can provide prompt notification via Email, Syslog Message or SNMP Trap.

Notes:

• The Circuit Breaker Open Alarm is not applicable to some VMR models.

• In order for the VMR/NPS to provide alarm notification via Email,

communication parameters must first be defined as described in

Section 5.9.11.

• In order for the VMR/NPS to provide alarm notification via Syslog Message,

Syslog parameters must first be defined and Syslog Messages must be

enabled as described in Section 5.9.2 and Section 11.

• In order for the VMR/NPS to provide alarm notification via SNMP Trap, SNMP

parameters must first be defined, and SNMP Traps must be enabled as

described in Section 5.9.7 and Section 12.

To configure the Circuit Breaker Alarm, you must access the VMR/NPS command mode

using a password that permits Administrator Level commands. The Circuit Breaker

Open Alarm Configuration Menu offers the following parameters:

• TriggerEnable: Enables/Disables the trigger for this alarm. When Disabled, this

alarm will be suppressed. (Default = On.)

Note: To cancel an alarm without correcting the condition that caused the

alarm, simply toggle the Trigger Enable parameter Off and then back On again.

• ResendDelay: Determines how long the VMR/NPS will wait to resend an email

message generated by this alarm, when the initial attempt to send the notification

was unsuccessful. (Default = 60 Minutes.)

• NotifyUponClear: When this item is enabled, the unit will send additional

notification when the situation that caused the alarm has been corrected. For

example, when Notify Upon Clear is enabled, the unit can send initial notification

when it detects an open circuit breaker, and then send a second notification when it

determines that the circuit breaker has been closed. (Default = On.)

• EmailMessage: Enables/Disables email notification for this alarm. (Default = On.)

Note: The Email Message parameter offers four different options: On, Off, On

(Copy to All Triggers) or Off (Copy to All Triggers). If either of the "Copy to All

Triggers" options is selected, then email notification for all other alarms will be

switched On or Off as indicated by this parameter.

• Address1,2,and3: These parameters are used to select which of the three email

addresses defined via the "Email Messages" menu (see Section 5.9.11) will receive

the email alarm notification messages generated by this alarm. The Address

parameters can be used to select one, or any combination of the addresses defined

via the Email Messages menu. (Default = All On.)

Note: If Email addresses have been previously defined, then the text under the

parameters will list the current, user selected email addresses.

• Subject: Defines the text that will appear in the "Subject" field for email notification

messages generated by this alarm. (Default = "Alarm: Circuit Breaker Open")
