7-6

Alarm Configuration

7.2. The Over Temperature Alarms

The Over Temperature Alarms are designed to inform you when the temperature level

inside your equipment rack reaches or exceeds certain user-defined levels. There

are two separate Over Temperature Alarms; the Initial Threshold alarm and the Critical

Threshold Alarm.

Typically, the Initial Threshold alarm is used to notify you when the temperature within

your equipment rack reaches a point where you might want to investigate it, whereas the

Critical Threshold alarm is used to notify you when the temperature approaches a level

that may harm equipment or inhibit performance. The trigger for the Initial Threshold

alarm is generally set lower than the Critical Threshold alarm.

If the user-defined trigger levels for temperature are exceeded, the VMR/NPS can

automatically shut off power to non-essential devices ("Load Shedding") in order to

reduce the amount of temperature that is being generated within the rack. In addition,

the Load Shedding feature can also be used to switch On additional components, such

as fans or cooling systems in order to dissipate the excess heat. After Load Shedding

has taken place, the Load Shedding Recovery feature can be used to return plugs to

their previous state after the temperature drops to an acceptable level.

Notes:

• In order for the VMR/NPS to provide alarm notification via Email,

communication parameters must first be defined as described in

Section 5.9.11.

• In order for the VMR/NPS to provide alarm notification via Syslog Message,

Syslog parameters must first be defined and Syslog Messages must be

enabled as described in Section 5.9.2 and Section 11.

• In order for the VMR/NPS to provide alarm notification via SNMP Trap, SNMP

parameters must first be defined, and SNMP Traps must be enabled as

described in Section 5.9.7 and Section 12.

To configure the Over Temperature Alarms, access the VMR/NPS command mode

using a password that permits Administrator Level commands, and then use the Alarm

Configuration menu to select the desired alarm feature.

Note that both the Initial Threshold menus and Critical Threshold menus offer essentially

the same parameters, but the parameters defined for each alarm are separate and

unique. Therefore, parameters defined for the Critical Threshold Alarm will not be

applied to the Initial Threshold Alarm and vice versa.

Both the Over Temperature (Initial Threshold) alarm and the Over Temperature (Critical

Threshold) alarm offer the following parameters:

• TriggerEnable: Enables/Disables the trigger for this alarm. When Disabled, this

alarm will be suppressed. (Default = On.)

Note: To cancel an alarm without correcting the condition that caused the

alarm, simply toggle the Trigger Enable parameter Off and then back On again.

• AlarmSetThreshold: The trigger level for this alarm. When temperature exceeds

the Alarm Set Threshold, the VMR/NPS can send an alarm (if enabled) and/or begin

Load Shedding (if enabled.) For more information on Load Shedding for the Over

Temperature Alarm, please refer to Section 7.2.1. (Initial Threshold: Default = 90°F

or 32°C, Critical Threshold: Default = 100°F or 38°C.)
