6-2

Reboot Options

6.1. Ping-No-Answer Reboot

A Ping-No-Answer Reboot can be used to reboot one or more outlets when an attached

device does not respond to a Ping Command. In addition, the Ping-No-Answer Reboot

feature can also be configured to send an email, Syslog Message or SNMP Trap to

notify you whenever a Ping-No-Answer Reboot occurs. Please refer to Section 7.5 for

instructions on setting up email alarm notification for Ping-No-Answer reboots.

To set up a Ping-No-Answer Reboot, you must access command mode using a

password that permits Administrator level commands. In the Text Interface, the Ping-No-

Answer configuration menu is accessed via the Reboot Options menu (/RB). In the Web

Browser Interface, the Ping-No-Answer configuration menu is accessed via the Reboot

Options link. The Ping-No-Answer configuration menu can be used to Add, Modify,

View or Delete Ping-No-Answer Reboot functions.

Note: In order for the Ping-No-Answer Reboot feature to work properly, your

network and/or firewall, as well as the device at the target IP address must be

configured to allow ping commands.

6.1.1. Adding Ping-No-Answer Reboots

Up to 54 Ping-No-Answer Reboots can be defined. The Add Ping-No-Answer menu is

used to define the following parameters for each new Ping-No-Answer Reboot:

• IPAddressorDomainName: The IP address or Domain Name for the device

that you wish to Ping. When the device at this address fails to respond to the Ping

command, the VMR/NPS will reboot the selected outlets. (Default = undefined.)

Note: In order to use Domain Names, you must first define DNS parameters as

described in Section 5.9.5.

• PingInterval: Determines how often the Ping command will be sent to the

selected IP Address. The Ping Interval can be any whole number, from 1 to 3,600

seconds. (Default = 60 Seconds.)

Note: If the Ping Interval is set lower than 20 seconds, it is recommended to

define the "IP Address or Domain Name" parameter using an IP Address rather

than a Domain Name. This ensures more reliable results in the event that the

Domain Name Server is unavailable.

• IntervalAfterFailedPing: Determines how often the Ping command will be sent

after a previous Ping command receives no response. (Default = 10 Seconds.)

• PingDelayAfterPNAAction: Determines how long the VMR/NPS will wait to

send additional Ping commands, after a Ping-No-Answer Reboot has been initiated.

Typically, this option is used to allow time for a device to fully "wake up" after a

Ping-No-Answer Reboot before attempting to Ping the device again.

(Default = 15 Minutes.)

• ConsecutiveFailures: Determines how many consecutive failures of the Ping

command must be detected in order to initiate a Ping-No-Answer Reboot. For

example, if this value is set to "3", then after three consecutive Ping failures, a

Ping-No-Answer Reboot will be performed. (Default = 5.)
