Basic Configuration

5.3. Defining System Parameters

The System Parameters menus are used to define the Site ID Message, set the system

clock and calendar, and configure the Invalid Access Lockout feature and Callback

feature.

To access the System Parameters menu via the Text Interface, type /F and press

[Enter]. To access the System Parameters menu via the Web Browser Interface, place

the cursor over the "General Parameters" link, wait for the flyout menu to appear and

then click on the "System Parameters" link. The System Parameters Menus are used to

define the following:

• UserDirectory: This function is used to view, add, modify and delete user

accounts and passwords. As discussed in Section 5.4 and Section 5.5, the User

Directory allows you to set the security level for each account as well as determine

which plugs each account will be allowed to control.

Note: The "User Directory" option does not appear in the Web Browser

Interface’s System Parameters menu, and is instead, accessed via the "User

Configuration" link on the left hand side of the menu.

• SiteID: A text field, generally used to note the installation site or name for the

VMR/NPS unit. (Default = undefined.)

• RealTimeClock: This prompt provides access to the Real Time Clock menu,

which is used to set the clock and calendar, and to enable and configure the NTP

(Network Time Protocol) feature as described in Section 5.3.1.

Note: The "Real Time Clock" option does not appear in the Web Browser

Interface’s System Parameters menu, and is instead, accessed via the "Real

Time Clock" link in the General Parameters fly-out menu.

• InvalidAccessLockout: If desired, this feature can be used to automatically

disable the VMR/NPS Setup Port or Network Port after a user specified number

of unsuccessful login attempts are made. For more information, please refer to

Section 5.3.2. (Default = On.)

Note: The "Invalid Access Lockout" item does not appear in the Web Browser

Interface’s System Parameters menu, and is instead, accessed via the link in the

General Parameters fly-out menu.

• TemperatureFormat: Determines whether the temperature is displayed as

Fahrenheit or Celsius. (Default = Fahrenheit.)

• TemperatureCalibration: Used to calibrate the unit's internal temperature sensing

abilities. To calibrate the temperature, place a thermometer inside your equipment

rack, in a location that usually experiences the highest temperature. After a few

minutes, take a reading from the thermometer, and then key the reading into the

configuration menu. In the Web Browser Interface, the temperature is entered

at the System Parameters menu, in the Temperature Calibration field; in the Text

Interface, the temperature is entered in a submenu of the System Parameters menu,

accessed via the Temperature Calibration item. (Default = undefined.)
