17-9

Command Reference Guide

17.3.3. Configuration Commands

/F Set System Parameters

Displays a menu which is used to define the Site ID message, create user accounts,

set the system clock, enter the unit serial number and configure and enable the Invalid

Access Lockout feature. Note that all functions provided by the /F command are

also available via the Web Browser Interface. For more information, please refer to

Section 5.3.

Availability: Administrator

Format: /F [Enter]

/P Set Serial Port Parameters

Displays a menu that is used to select options and parameters for the VMR/NPS's serial

Setup Port, Remote Port. Note that all functions provided by the /P command are

also available via the Web Browser Interface. Section 5.8 describes the procedure for

defining serial port parameters for the Setup Port.

Availability: Administrator

Format: /P [Enter]

/PL Set Plug Parameters

Displays a menu that is used to select options and parameters for the VMR/NPS's

switched outlets (plugs). Note that all functions provided by the /PL command are

also available via the Web Browser Interface. Section 5.7 describes the procedure for

defining plug parameters.

Availability: Administrator

Format: /PL [Enter]

/G Plug Group Parameters

Displays a menu that is used to View, Add, Modify or Delete Plug Groups. For more

information on Plug Groups, please refer to Section 5.6.

Availability: Administrator

Format: /G [Enter]

/N Network Port Parameters

Displays a menu which is used to select parameters for the Network Port. Also allows

access to the IP Security function, which can restrict network access by unauthorized IP

addresses. Note that all of the functions provided by the /N command are also available

via the Web Browser Interface. For more information, please refer to Section 5.9.

Availability: Administrator

Format: /N [Enter]
