17-5
Command Reference Guide
17.3.2. Control Commands
/X Exit Command Mode
Exits command mode. When issued at the Network Port, also ends the Telnet session.
Note: If the /X command is invoked from within a configuration menu, recently
defined parameters may not be saved. In order to make certain that parameters
are saved, always press the [Esc] key to exit from all configuration menus and
then wait until "Saving Configuration" message has been displayed and the
cursor has returned to the command prompt before issuing the /X command.
Availability: Administrator, SuperUser, User, ViewOnly
Format: /X [Enter]
/BOOT Initiate Boot Cycle
Initiates a boot cycle at the selected plug(s) or Plug Group(s). When a Boot cycle is
performed, the VMR/NPS will first switch the selected plug(s) Off, then pause for the
user-defined Boot/Sequence Delay Period, then switch the plug(s) back on. The /BOOT
command can also be entered as /BO.
Note: When this command is invoked in Administrator Mode or SuperUser
Mode, it can be applied to all VMR/NPS plugs and Plug Groups. When this
command is invoked in User Mode, it can only be applied to the plugs and/or
Plug Groups that have been enabled for the account.
Availability: Administrator, SuperUser, User
Format: /BOOT <s>[,Y] [Enter] or /BO <s> [Enter]
Where:
s The number or name of the plug(s) or Plug Group(s) that you intend to
boot. To apply the command to several plugs, enter a plus sign (+)
between each plug number. To apply the command to a range of plugs,
enter the numbers for the first and last plugs in the range, separated by a
colon character (:). To apply the command to all plugs allowed by your
account, enter an asterisk character (*).
,Y (Optional) Suppresses the command confirmation prompt.
Example:
Assume that your account allows access to Plug A2 and Plug A3. To initiate a boot
cycle at Plugs A2 and A3, without displaying the optional command confirmation
prompt, invoke either of the following command lines:
/BOOT A2+A3,Y [Enter] or /BO A2+A3,Y [Enter]
