17-2
Command Reference Guide
17.2. Command Summary
Function Command Syntax Command Access Level
Admin. SuperUser User ViewOnly
Display
Plug Status /S [s] [Enter] X X X X
Plug Group Status /SG [Enter] X X X X
Network Status /SN [Enter] X X X X
Help Menu /H [Enter] X X X X
Log Functions /L [Enter] X X
Current Metering /M [Enter] X X
Site ID / Unit Information /J [*] [Enter] X X X X
Control
Exit Command Mode /X [Enter] X X X X
Boot Plug n /BOOT <s>[,Y] [Enter] X X X
Turn Plug n On /ON <s>[,Y] [Enter] X X X
Turn Plug n Off /OFF <s>[,Y] [Enter] X X X
Default All Plugs /DPL[,Y] [Enter] X X X
Connect to Port /C [n] [Enter] X X X
Disconnect from Port /D [n][Enter] X X X
Send Parameter File /U [Enter] X
Send SSH Keys /K <k> [Enter] X
Unlock Invalid Access /UL [Enter] X
Configuration
System Parameters /F [Enter] X
Serial Port Parameters /P [n] [Enter] X
Plug Parameters /PL [Enter] X
Plug Group Parameters /G [Enter] X
Network Configuration /N [Enter] X
Reboot Options /RB [Enter] X
Alarm Configuration /AC [Enter] X
Reboot System /I [Enter] X X
Upgrade Firmware /UF [Enter] X
Test Network Configuration /TEST [Enter] X
In Administrator Mode and SuperUser Mode, all VMR/NPS outlets are displayed. In User
Mode and ViewOnly Mode, the Plug Status Screen will only include the plugs that are allowed
by your account.
In Administrator Mode, all Plug Groups are displayed. In SuperUser Mode, User Mode and
ViewOnly Mode, the Plug Group Status Screen will only include the Plug Groups that are
allowed by your account.
In Administrator Mode, the Help Menus will list all VMR/NPS commands. In the SuperUser
Mode, User Mode and ViewOnly Mode, the Help Menus will only list the commands that are
allowed by the access level.
Current and Metering functions are not available on NPS units.
If the optional asterisk (*) argument is included in the command line, this command will also
show model numbers, current ratings and software versions for the VMR/NPS unit.
The ",Y" argument can be included in the command line to suppress the command
confirmation prompt.
Not applicable to VMR/NPS units.
In SuperUser Mode, configuration menus can be displayed, but parameters cannot be
changed.
