13-6

Operation via SNMP

13.5. Viewing VMR/NPS Status via SNMP

Status of various components of the VMR/NPS can be retrieved via SNMP. Plug Status,

and Environmental Status are currently supported.

13.5.1. Plug Status

The status of each plug in the system can be retrieved using the command below.

• plugTable::plugStatus – The status of the plug.

0 – Plug is OFF

1 – Plug is ON

• plugTable::plugName - String indicating the plug's user-defined name.

13.5.2. Unit Environment Status

The environment status can be retrieved for various variables for all of the VMR/NPS

units in the system. The environmentUnitTable contains four rows, one row for each unit

in the system (LOCAL, AUX1, AUX2, AUX3.)

Note: Current and Power Monitoring features are not available on NPS units.

• environmentUnitTable::environmentUnitName – The unit (LOCAL.)

• environmentUnitTable::environmentUnitTemperature – The temperature

of the given unit.

• environmentUnitTable::environmentUnitCurrentA – (VMR Only) Unit's

total current for Branch A. Note that Current will be reported in tenths of an Amp

(divide result by ten to determine value in Amps.)

• environmentUnitTable::environmentUnitVoltageA – (VMR Only) Unit

voltage for Branch A

• environmentUnitTable::environmentUnitPowerA – (VMR Only) Power

drawn by Branch A

• environmentUnitTable::environmentUnitCurrentB – (VMR Only) Unit's

total current for Branch B. Note that Current will be reported in tenths of an Amp.

• environmentUnitTable::environmentUnitVoltageB – (VMR Only) Unit

voltage for Branch B

• environmentUnitTable::environmentUnitPowerB – (VMR Only) Power

drawn on Branch B

• environmentMonthlyPowerLog - (VMR Only) The monthly power usage log.
