11. Syslog Messages
The Syslog feature can create log records of each Alarm Event. As these event records
are created, they are sent to a Syslog Daemon, located at an IP address defined via the
Network Parameters menu.
11.1. Configuration
If you wish to employ this feature, you must set the real-time clock and calendar via the
System Parameters Menu, and define the IP address for the Syslog Daemon via the
Network Port Configuration menu.
To configure the Syslog function, please proceed as follows:
1. Accesscommandmode: Note that the following configuration menus are only
available to accounts that permit Administrator level commands.
2. SystemParametersMenu: Access the System Parameters Menu as described in
Section 5.3, then set the following parameters:
a) SetClockandCalendar: Set the Real Time Clock and Calendar and/or
configure and enable the NTP server feature.
3. NetworkParametersMenu: Access the Network Parameters Menu as described
in Section 5.9, then set the following parameters:
a) SyslogIPAddress: Determine the IP address for the device that will run the
Syslog Daemon, then use the Network Port Configuration menu to define the IP
Address for the Syslog Daemon.
Note: The Syslog Address submenu in the Text Interface includes a Ping Test
function that can be used to ping the user-selected Syslog IP Address to verify
that a valid IP address has been entered. In order for the Ping Test feature
to function, your network and/or firewall must be configured to allow ping
commands.
4. SyslogDaemon: In order to capture messages sent by the VMR/NPS, a computer
must be running a Syslog Daemon (set to UDP Port 514) at the IP address specified
in Step 3 above.
Once the Syslog Address is defined, Syslog messages will be generated whenever one
of the alarms discussed in Section 7 is triggered.
