9-7

Operation

9.4. Manual Operation

In addition to the command driven functions available via the Web Browser Interface

and Text Interface, some VMR/NPS functions can also be controlled manually. For a

summary of front panel control functions, please refer to Section 2.3.

9.5. Logging Out of Command Mode

When you have finished communicating with the VMR/NPS, it is important to always

disconnect using either the "LogOut" link (Web Browser Interface) or the /X command

(Text Interface), rather than by simply closing your browser window or communications

program. When communicating via a PDA, use the PDA's "Close" function to disconnect

and logout.

When you disconnect using the LogOut link or /X command, this ensures that the VMR/

NPS has completely exited from command mode, and is not waiting for the inactivity

timeout period to elapse before allowing additional connections.
